Overview
The Emerson PR6424/01 CS CON021 is an 8 mm eddy‑current proximity sensor module from the EPRO series, engineered for precise, non‑contact measurement of shaft displacement and vibration in rotating machinery. Its stable signal characteristics and rugged construction make it suitable for continuous condition monitoring and machinery protection applications across demanding industrial environments.
Functional Characteristics
This module operates as part of a complete eddy‑current measurement chain, delivering accurate displacement and vibration data for turbines, compressors, pumps, and other high‑speed rotating assets. The sensor is designed to maintain measurement integrity under harsh conditions, including elevated temperatures, oil contamination, and mechanical vibration.
The PR6424/01 CS CON021 integrates seamlessly with CON021‑series signal conditioning units and AMS 6500 Classic monitoring systems, ensuring compatibility with both legacy and modern installations. Its fast response and high sensitivity support early detection of mechanical degradation, enabling predictive maintenance strategies that reduce downtime and extend equipment life.
Technical Specifications
| Parameter |
Specification |
| Model |
PR6424/01 CS |
| Part Number |
CON021 |
| Product Type |
8 mm Eddy Current Sensor Module |
| Probe Diameter |
8 mm |
| Measurement Principle |
Non‑contact eddy current displacement |
| Typical Applications |
Shaft vibration, axial/radial displacement |
| System Platform |
EPRO / AMS 6500 Classic |
| Output Compatibility |
Works with CON021 signal converters |
| Operating Environment |
High‑temperature, oil‑contaminated, vibration‑intense zones |
| Dimensions |
17 × 3.7 × 21 cm |
| Weight |
0.46 kg |
| Country of Origin |
USA |
| HS Code |
8537101190 |
| System Type |
DCS / Condition Monitoring |
| Availability |
In stock |
Performance Description
The PR6424/01 CS CON021 provides high‑resolution, real‑time displacement and vibration data, enabling operators to identify early‑stage mechanical issues such as bearing wear, rotor instability, or misalignment. Its compact 8 mm probe design is ideal for installations with limited mounting space while still delivering excellent measurement accuracy.
The sensor’s durable construction ensures long‑term reliability in harsh industrial environments. Its compatibility with a wide range of monitoring systems allows straightforward integration into existing automation architectures, supporting efficient maintenance planning and improved operational stability.
Application Scenarios
-
Turbine and generator shaft monitoring
-
Compressor and pump displacement measurement
-
Machinery protection systems in petrochemical and power facilities
-
High‑speed rotating equipment in manufacturing
-
Predictive maintenance and continuous monitoring programs
FAQ
Q: What differentiates the PR6424/01 CS from other PR6424 variants? A: The “01 CS” configuration defines probe length and calibration range, optimized for specific installation requirements.
Q: What signal converter is required? A: It must be paired with a compatible CON021 signal conditioning module.
Q: Can this sensor operate in high‑temperature environments? A: Yes, the PR6424 series is engineered for elevated temperatures and harsh industrial conditions.
