Overview
The Emerson EPRO PR6424/006-030 + CON021 is a high-precision 16mm eddy current sensor system designed for monitoring vibration and displacement in industrial machinery. Paired with the CON021 signal converter, this sensor provides reliable, linear output suitable for critical machinery diagnostics and predictive maintenance applications.
Technical Specifications
| Feature |
Specification |
| Sensor Type |
16mm Eddy Current Sensor |
| Model & Part Number |
PR6424/006-030 |
| Signal Converter |
CON021 |
| Sensitivity / Linearity |
4 V/mm (101.6 mV/mil) ±1.5% |
| Nominal Air Gap |
~2.7 mm (0.11 in) |
| Static Measurement Range |
±2.0 mm (0.079 in) |
| Dynamic Measurement Range |
0–1,000 µm (0–0.039 in) |
| Minimum Shaft Diameter |
≥80 mm |
| Operating Temperature |
-35 to 180°C (-31 to 356°F) |
| Weight (Sensor + 1m Cable) |
200 g (7.05 oz) |
| Cable Length |
1 m standard (no armor) |
| Mounting |
Standard 16mm sensor housing for industrial shafts |
Applications
-
Monitoring vibration in rotating machinery such as motors, pumps, and turbines
-
Predictive maintenance and condition monitoring
-
Shaft alignment verification and machinery diagnostics
FAQ
Q: Can this sensor be used on shafts smaller than 80 mm?
A: No, the minimum recommended shaft diameter is 80 mm to ensure accurate measurement and sensor alignment.
Q: What is the maximum operating temperature for long-term use?
A: Continuous operation is recommended up to 180°C (356°F). Short-term spikes above this temperature may affect sensor longevity.
Q: Can the CON021 signal converter be replaced with another model?
A: The sensor is specifically calibrated for the CON021. Using a different converter may affect measurement accuracy.
