The Emerson Ovation 5X00300G02 is a high-performance analog output module engineered for precise control in Ovation Distributed Control Systems (DCS). This module converts digital control commands into stable analog signals, supporting a variety of industrial process applications. Its high accuracy, fast response, and robust diagnostics make it suitable for critical operations in energy, water, and manufacturing sectors.
Key Features
-
High-Precision Output: 16-bit resolution with ±0.1% full-scale accuracy ensures reliable and precise analog signals.
-
Versatile Output Range: Supports -10V to +10V output, compatible with a wide range of industrial control devices.
-
Rapid Response: 250 ms update rate allows the module to reflect process changes in near real-time.
-
Integrated Fault Detection: Built-in diagnostics enhance operational reliability and reduce potential downtime.
-
Compact Design: Small form factor (173 × 100 × 42 mm) simplifies installation and integration into dense control racks.
-
Durable Operation: Rated for extreme temperatures (-40°C to +70°C) and reliable 24VDC operation.
Technical Specifications
| Parameter |
Specification |
| Model Number |
5X00300G02 |
| Product Type |
Analog Output Module |
| Number of Channels |
16 |
| Output Range |
-10V to +10V |
| Accuracy |
±0.1% full scale |
| Resolution |
16-bit |
| Update Rate |
250 ms |
| Power Supply |
24VDC, 200 mA |
| Operating Temperature |
-40°C to +70°C |
| Dimensions |
173 × 100 × 42 mm (6.81" × 3.94" × 1.65") |
| Weight |
~0.72 kg |
| Diagnostics |
Built-in fault detection and signaling |
| Mounting |
Rack or panel mount compatible |
Applications
-
Distributed Control Systems for power plants
-
Industrial process control in water and wastewater facilities
-
Oil, gas, and chemical process control
-
Manufacturing automation requiring high-precision analog outputs
FAQ
Q: Can this module handle simultaneous high-speed updates for all 16 channels?
A: Yes, the 250 ms update rate applies to all channels, ensuring consistent and synchronized analog output performance.
Q: Is it compatible with older Ovation analog output modules?
A: The 5X00300G02 integrates seamlessly into existing Ovation DCS installations, maintaining backward compatibility with prior module generations.
Similar Models Comparison
-
5X00299G01: Lower resolution (12-bit), slower update rate, suitable for less demanding applications.
-
5X00301G03: Extended voltage range (-15V to +15V) with slightly higher power consumption for advanced control scenarios.
