Product Description
Overview
The Emerson Ovation 5X00119G02 is an 8-channel RTD input module designed for precise temperature measurement in demanding industrial processes. Engineered for seamless integration with the Ovation Distributed Control System (DCS), it provides accurate, real-time monitoring for applications such as power generation, water treatment, and industrial manufacturing.
Key Features
-
Supports multiple RTD types, including PT100, T1000, Ni20, and other standard RTDs
-
Wide measurement range from −200 °C to +850 °C (−328 °F to +1562 °F), depending on RTD type
-
High input impedance to minimize signal loss and maintain accuracy
-
16-bit analog-to-digital conversion with ±0.1% full-scale accuracy
-
Fast data update rate: <100 ms per channel
-
Nominal power requirement: 24 VDC
-
Operating temperature range: −20 °C to +70 °C, storage range: −40 °C to +85 °C
-
Humidity tolerance: 5%–95% non-condensing
-
Compact dimensions: 180 mm height × 50 mm width × 120 mm depth
-
Lightweight: 0.8 kg
-
Certified CE, UL, and RoHS compliant
Technical Specifications
| Parameter |
Specification |
| Model Number |
5X00119G02 |
| Channels |
8 |
| Supported RTD Types |
PT100, T1000, Ni20, other common RTDs |
| Temperature Range |
−200 °C to +850 °C (dependent on RTD type) |
| Input Impedance |
High impedance for minimal signal degradation |
| Accuracy |
±0.1% full scale |
| Resolution |
16-bit ADC |
| Update Rate |
<100 ms per channel |
| Power Supply |
24 VDC nominal |
| Operating Temperature |
−20 °C to +70 °C |
| Storage Temperature |
−40 °C to +85 °C |
| Humidity |
5%–95% non-condensing |
| Dimensions (H×W×D) |
180 mm × 50 mm × 120 mm |
| Weight |
0.8 kg |
| Certifications |
CE, UL, RoHS |
Applications
Ideal for precise temperature monitoring in critical industrial processes such as power plants, water treatment facilities, and manufacturing lines. The module enables accurate process control, real-time data acquisition, and high system reliability.
FAQ
Q: Which RTD types can be used with this module?
A: The 5X00119G02 supports PT100, T1000, Ni20, and other common RTD sensors.
Q: What is the module’s temperature measurement range?
A: It can measure from −200 °C to +850 °C, depending on the RTD sensor used.
Q: Can it operate in harsh environments?
A: Yes, it functions reliably from −20 °C to +70 °C and is designed for industrial conditions.
Similar Models Comparison
-
5X00118G02: 4-channel RTD module, smaller footprint
-
5X00120G02: 16-channel RTD module, extended input capacity
