The Ovation 5X00109G01 is a high-performance 8-channel analog input module featuring HART communication compatibility. Designed for demanding industrial environments, this personality module delivers precise signal acquisition, robust system integration, and long-term reliability. All units are Emerson factory-certified, ensuring consistent performance and system integrity.
Technical Specifications
| Feature |
Specification |
| Channels |
8 analog inputs |
| Signal Type |
Voltage/current with HART protocol support |
| Communication Interface |
HART-compatible analog input |
| Input Range |
Configurable per process requirements |
| Accuracy |
High precision, typical ±0.1% of reading |
| Isolation Voltage |
1500 VAC between module and system |
| Status Indicators |
Channel-specific LEDs |
| Mounting |
DIN rail compatible |
| Operating Temperature |
-20°C to 70°C |
| Storage Temperature |
-40°C to 85°C |
| Humidity |
5–95% RH, non-condensing |
| Dimensions |
Standard Ovation I/O module form factor |
| Certification |
Emerson Factory-Certified |
Key Features
-
Supports HART-enabled devices for advanced digital diagnostics
-
8-channel configuration provides flexible input coverage
-
Factory-certified to maintain Ovation system performance
-
Compact and durable design suitable for harsh industrial conditions
-
Simplifies installation and maintenance with LED indicators and standard mounting
Applications
-
Continuous process monitoring and control
-
Power generation and distribution systems
-
Oil, gas, and petrochemical instrumentation
-
Water treatment and wastewater management
-
Food and beverage process monitoring
FAQ
Q: Is the module compatible with non-HART devices?
A: Yes, it supports standard analog signals while providing HART functionality for compatible devices.
Q: What is the maximum input voltage it can safely handle?
A: Input ranges are configurable according to the process signal, typically within standard Ovation analog voltage/current specifications.
Q: Does Emerson provide factory certification for all units?
A: Yes, each 5X00109G01 module is Emerson factory-tested to ensure system compatibility and operational reliability.
Similar Models Comparison
| Model |
Channels |
Protocol |
Isolation |
Key Feature |
| 5X00109G01 |
8 |
HART |
1500 VAC |
Factory-certified personality module |
| 5X00108G01 |
8 |
Standard Analog |
1500 VAC |
Non-HART version for general signals |
| 5X00107G01 |
16 |
Standard Analog |
1500 VAC |
Higher channel count, standard signals |
