Product Description
Overview
The Emerson Ovation 5A26141G06 is a precision-engineered Local I/O Bus cable designed to interface directly with Emerson Ovation control systems. Measuring 4.5 feet in length, this cable features DB9 connectors at both ends, providing reliable and consistent communication between local I/O modules and the Ovation controller. Its robust construction ensures stable operation in demanding industrial environments.
Key Features
-
Cable Length: 4.5 feet
-
Connector Type: DB9 Male to Male
-
Data Transmission: RS-485
-
Maximum Baud Rate: 19.2 kbps
-
Operating Temperature: -40 to 85 degrees Celsius
-
Humidity Tolerance: 0 to 95 percent, non-condensing
-
Cable Type: Coaxial
-
Conductor Size: 24 AWG
-
Insulation Material: PVC
-
Jacket Material: PVC
-
Shielding: Braided and foil for EMI/RFI protection
-
Termination: Factory-assembled DB9 connectors
Applications
-
Connecting local I/O modules to Emerson Ovation controllers
-
Extending the reach of local I/O modules for flexible system design
-
Linking multiple local I/O modules to a single controller
Technical Specifications
| Parameter |
Specification |
| Cable Type |
Coaxial |
| Conductor Size |
24 AWG |
| Insulation |
PVC |
| Outer Jacket |
PVC |
| Shielding |
Braided and foil |
| Connector Type |
DB9 Male to Male |
| Length |
4.5 feet |
| Data Protocol |
RS-485 |
| Maximum Baud Rate |
19.2 kbps |
| Operating Temperature |
-40 to 85 C |
| Humidity |
0 to 95 percent non-condensing |
FAQ
Q: Can this cable be used with multiple I/O modules simultaneously?
A: Yes, the cable supports connecting multiple local I/O modules to a single Ovation controller, ensuring synchronized data communication.
Q: Is the cable suitable for harsh environments?
A: The cable operates reliably from -40 to 85 degrees Celsius and tolerates high humidity, making it suitable for industrial conditions.
Q: What is the maximum data rate supported?
A: The cable supports up to 19.2 kbps over the RS-485 interface.
Q: Are there compatible alternatives for longer distances?
A: Yes, Emerson offers extended-length bus cables and modular connection kits compatible with Ovation controllers.
