Overview
The 1C31232G02 from Emerson Ovation is a high-performance differential digital input module designed for integration with the Ovation Distributed Control System (DCS). It efficiently acquires and processes digital signals from field devices such as sensors, switches, and actuators, providing reliable operation even in challenging industrial environments.
Key Features
-
Handles 32 differential digital inputs simultaneously for extensive signal monitoring.
-
Fully optically isolated inputs to protect against electrical noise and ensure signal integrity.
-
High-speed response with acquisition times under 2 μs for precise system control.
-
Built-in diagnostics and fault detection simplify troubleshooting and maintenance.
-
User-friendly configuration and maintenance for improved operational efficiency.
Technical Specifications
| Specification |
Details |
| Input Voltage Range |
-40V to +40V DC |
| Input Current Range |
-1.5 mA to +1.5 mA |
| Input Impedance |
>100 kΩ |
| Response Time |
<2 μs |
| Accuracy |
±0.5% of full scale |
| Power Consumption |
2 W |
| Operating Temperature |
-40°C to +70°C |
| Storage Temperature |
-55°C to +85°C |
| Humidity |
5% to 95% RH (non-condensing) |
| Dimensions |
173 mm x 110 mm x 53 mm (6.8 x 4.3 x 2.1 in) |
| Weight |
1 kg (2.2 lb) |
Applications
Ideal for power generation, process control, and industrial automation systems where reliable, high-speed digital signal acquisition is critical. Suitable for environments with electrical noise or extreme temperatures.
FAQ
Q: Can this module interface with other DCS systems?
A: The 1C31232G02 is optimized for Emerson Ovation DCS. Integration with other systems may require interface adaptation.
Q: How are faults reported?
A: The module includes diagnostic outputs and error reporting signals compatible with Ovation monitoring software.
Q: Are there similar modules in the Ovation series?
A: Emerson Ovation also offers modules such as 1C31231G01 and 1C31233G03, which vary in input counts and isolation features.
