Product Description
Overview
The Emerson Ovation 1C31201G01 is a servo drive personalization module built for high-precision control of servomechanisms. Designed to provide reliable feedback for position and speed control, it integrates seamlessly with the Ovation Distributed Control System (DCS) to deliver consistent performance in industrial automation environments.
Key Features
-
High-accuracy servo control with built-in readback monitoring
-
Supports 1 kHz LVT output at 19 VPP for responsive control
-
Six independent output channels for versatile configuration
-
Robust design with 1000 VAC/DC isolation between channels and channel-to-logic
-
Advanced rejection of electrical noise: 60 dB normal-mode, 120 dB common-mode
-
Lightweight, low-power design: 2.5 W typical main power; 3.38 W maximum
-
Auxiliary power supply: 24 VDC, supporting up to 8 inputs at 20 mA each
-
Wide operating temperature: 0 °C to 60 °C; storage −40 °C to 85 °C
-
Supports relative humidity up to 95% non-condensing
Technical Specifications
| Parameter |
Specification |
| Model Number |
1C31201G01 |
| Module Type |
Servo Drive Personalization Module |
| Manufacturer |
Emerson |
| Channels |
6 |
| Output |
1 kHz LVT, 19 VPP |
| Operating Temperature |
0 °C to 60 °C |
| Storage Temperature |
−40 °C to 85 °C |
| Humidity |
0–95% non-condensing |
| Main Power Consumption |
2.5 W typical, 3.38 W maximum |
| Auxiliary Power Consumption |
3.84 W typical (8 inputs @ 20 mA each) |
| Auxiliary Power Supply Voltage |
24 VDC |
| Isolation |
1000 VAC/DC channel-to-channel and channel-to-logic |
| Noise Rejection |
Normal-mode: 60 dB at 50/60 Hz; Common-mode: 120 dB at DC, powerline frequency, and harmonics |
Applications
Ideal for precise motion control in turbines, pumps, and other servo-driven industrial equipment. The module ensures accurate speed and position feedback for critical process automation.
FAQ
Q: How many channels does the module provide?
A: The 1C31201G01 module supports 6 independent channels.
Q: What type of output does it support?
A: It provides 1 kHz LVT output at 19 VPP for responsive control feedback.
Q: Can this module operate in high-humidity environments?
A: Yes, it supports 0–95% non-condensing humidity.
