Product Description
Overview
The Emerson Ovation 1C31116G05 Rev 15 is an analog input module engineered for high-precision data acquisition in industrial control systems. It converts analog signals from field sensors into digital data suitable for processing by Ovation controllers. Typical applications include temperature, pressure, flow, and vibration monitoring.
Key Features
-
Multiple independent analog input channels for versatile monitoring
-
High-accuracy signal conversion to ensure precise control system readings
-
Built-in channel isolation to prevent electrical interference
-
Calibration capability for reliable long-term performance
-
Compact, modular design compatible with Emerson Ovation systems
Technical Specifications
-
Model: 1C31116G05 Rev 15
-
Input type: Analog voltage or current signals
-
Number of channels: 8–16 (depending on system configuration)
-
Input range: 0-10V, 4-20mA standard
-
Resolution: 16-bit
-
Accuracy: ±0.1% of full scale typical
-
Response time: 10 ms typical
-
Isolation: Channel-to-channel and channel-to-system isolation
-
Power supply: 24VDC standard
-
Operating temperature: 0 to 60 degrees Celsius
-
Mounting: Rack or panel compatible
-
Certification: CE, UL
Applications
-
Process control in power generation and utilities
-
Industrial plant monitoring systems
-
Data acquisition for predictive maintenance
-
Integration with Emerson Ovation DCS controllers
Similar Models Comparison
The 1C31116G05 is comparable to models such as 1C31117G05 and 1C31118G05. The primary differences are in channel count, input range options, and response times. This model offers a balanced combination of channel density, accuracy, and speed suitable for most control environments.
FAQ
Q: Can this module handle thermocouple inputs?
A: Yes, with appropriate signal conditioning or interface cards.
Q: Is channel isolation included?
A: Yes, each channel is electrically isolated to prevent interference.
Q: What type of controllers is it compatible with?
A: Designed for Emerson Ovation DCS series controllers.
