Description

Product Description

Overview

The Emerson Ovation 1B30023H02 I/O Branch Terminator is designed to provide accurate termination for local I/O branches without an Attachment Unit Module (AUM). It ensures stable communication, prevents signal reflections, and guarantees reliable data transfer across the Ovation control system. This module supports flexible installation on either side of standard I/O bases.

Technical Specifications

Compatibility

• Suitable for I/O branches that do not use an Attachment Unit Module

• Can be installed on both A-side and B-side of standard I/O bases

Electrical Requirements

• Operating voltage: +24 VDC

• Supports redundant power configurations for enhanced reliability

Communication Performance

• Effectively terminates the local I/O communication bus

• Prevents signal reflection and maintains data integrity

• Ensures consistent performance across the Ovation I/O network

Physical & Installation

• Compact design compatible with standard Ovation I/O bases

• Can be mounted on either side of the base for minimal system downtime

Application Scenarios

• Ideal for industrial plants using Emerson Ovation systems where certain I/O branches operate without an AUM

• Ensures reliable I/O communication in critical process control environments

FAQ

Q: Can this module be used on branches with an AUM?
A: No, this module is specifically designed for branches without an AUM.

Q: Does it support dual redundant power supplies?
A: Yes, redundant power configurations are supported to enhance system reliability.

Q: Are there installation restrictions regarding side placement?
A: No, it can be installed on either side (A or B) of a standard I/O base.

Similar Model Comparison

Model	Key Features	Application
1B30023H02	No AUM terminator, supports redundant power, dual-side installation	Local I/O branches without AUM
1B30024H01	Terminator with AUM support, standard power	Branches with AUM
1B30025H03	High-temperature environment module	High-temperature industrial applications

Specifications

• Brand: EMERSON

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
