Description
Overview
The MMS6823 data acquisition module is part of Emerson’s IMR 6000/00 System, designed to collect, preprocess, and transmit measurement data from industrial machinery. Its architecture supports high‑speed sampling and stable operation in demanding environments, making it suitable for integration into distributed control and monitoring platforms.
Functional Characteristics
The MMS6823 serves as an interface between field sensors and higher‑level monitoring systems. It digitizes analog input signals, applies internal filtering and scaling, and forwards processed data to supervisory systems through the IMR 6000/00 communication backbone. Its compact housing and robust electronics ensure consistent performance under electrical noise, temperature variations, and mechanical vibration.
The module is engineered for continuous operation and supports deterministic data transfer, enabling accurate trend analysis and event detection. Its design allows straightforward installation in existing IMR 6000/00 racks without requiring system redesign.
Technical Specifications
| Parameter |
Specification |
| Model |
MMS6823 |
| Product Type |
Data Acquisition Module |
| Brand |
Emerson |
| Product Range |
IMR 6000/00 System |
| Origin |
USA |
| Weight |
0.28 kg |
| Dimensions |
6 × 18.8 × 12.8 cm |
| System Compatibility |
DCS |
| Input Type |
Analog sensor inputs (voltage/current) |
| Output |
Digitized data to IMR 6000/00 bus |
| Operating Voltage |
220 V AC |
| Internal Processing Frequency |
30 kHz |
| Construction |
Industrial‑grade module housing |
| HS Code |
8537101190 |
| MOQ |
1 |
| Lead Time |
In Stock |
Performance Notes
-
High‑frequency internal processing (30 kHz) supports fast‑changing signal environments.
-
Stable operation at 220 V AC for compatibility with industrial power systems.
-
Designed for long‑term reliability in harsh environments with electrical interference.
-
Compact form factor simplifies installation in IMR 6000/00 racks.
Application Scenarios
-
Machinery condition monitoring
-
Process data acquisition for DCS systems
-
Vibration, temperature, and pressure signal digitization
-
Large‑scale industrial automation platforms
-
Power generation and petrochemical monitoring systems
FAQ
Q: What systems support the MMS6823? A: It is designed specifically for the IMR 6000/00 System and integrates into DCS‑based architectures.
Q: What type of signals can it acquire? A: It accepts analog sensor inputs such as voltage or current signals commonly used in industrial monitoring.
Q: Is the module still available despite being discontinued? A: Yes. Although discontinued, replacement units remain available for maintenance of existing installations.
