Product Description
Overview
The Emerson KL2101X1-BB1 (SE6504) is a high-performance CHARM I/O Card designed for redundant CIOC2 configurations. Supplied as a pair, this module enhances system reliability and seamless integration within standard control cabinets. With robust protection, low power consumption, and user-configurable memory, it ensures consistent operation in demanding industrial environments.
Key Features
-
Supplied as a redundant pair for improved system reliability
-
Compatible with standard cabinets and DeltaV systems
-
Compact dimensions: 4.1 × 12.8 × 12.8 cm
-
IP65 front protection for dust and water resistance
-
Supports 256 kB of user memory for configuration and data logging
-
Low active power consumption of 6 W typical
-
Supports 4 blue-level display colors on a 5.7-inch micro TP screen
Technical Specifications
| Parameter |
Specification |
| Model Number |
KL2101X1-BB1 |
| Alternate Part Number |
SE6504 |
| Product Type |
CHARM I/O Card |
| Package |
Original packaging |
| Condition |
100% Original, Brand New |
| Screen Diagonal |
5.7 in |
| Number of Colors |
4 (Blue Levels) |
| MTBF Backlighting |
50,000 h at 25°C |
| Rated Current |
0.24 A |
| Starting Current Inrush |
0.5 A²·s |
| Active Power Input |
6 W typical |
| Memory Available for User Data |
256 kB |
| IP Rating |
IP65 (front) |
| Operating Temperature |
0°C to +50°C |
| Storage Temperature |
-40°C to +85°C |
| Weight |
0.25 kg |
| Shipping |
UPS, DHL, TNT, EMS |
| Payment |
T/T (Bank Transfer) |
| Warranty |
12 months |
| Service |
One-Stop Service |
Applications
Designed for critical control systems, the KL2101X1-BB1 CHARM I/O Card is ideal for redundant CIOC2 configurations, industrial automation, monitoring, and data acquisition applications. Its compact design and high protection rating allow installation in standard cabinets without compromising reliability.
FAQ
Q: Can these I/O cards operate in harsh environments?
A: Yes, the front panel is IP65-rated, and the cards operate between 0°C and 50°C, with storage up to 85°C.
Q: How much user data memory is available?
A: Each card provides 256 kB of memory for configuration and data logging.
Q: Are these cards compatible with standard cabinets?
A: Yes, they are designed to fit standard cabinets in redundant CIOC2 setups.
