The KJ4006X1‑BF1 (12P4728X052) SE4001S2T2B4 Redundant Analog Input Terminal Block is a compact, high‑reliability I/O component designed for DeltaV M‑series architectures. Engineered for stable field signal acquisition, it supports redundant operation and ensures continuous availability in demanding industrial control environments.
This module provides eight isolated analog input channels optimized for 4–20 mA current loops, offering dependable performance in process automation systems requiring precise measurement and robust diagnostics.
Key Features
-
Eight analog input channels with redundant architecture
-
Compatible with DeltaV M‑series I/O subsystem
-
Supports 4–20 mA DC input with overrange capability
-
Integrated diagnostics for channel health and power monitoring
-
Compact footprint for efficient cabinet utilization
-
Designed for harsh industrial environments
-
Fully supported by DeltaV configuration and monitoring tools
Technical Specifications
Electrical Characteristics
| Parameter |
Specification |
| Supported Signal Type |
4–20 mA DC (standard & overrange) |
| Input Range |
−5 mA to +25 mA |
| Input Impedance |
≤ 250 Ω |
| Field Power Requirement |
30 VDC, approx. 200 mA |
| Channel Count |
8 analog inputs |
| Redundancy |
Yes, dual‑path architecture |
Environmental Ratings
| Parameter |
Specification |
| Operating Temperature |
−40°C to +70°C |
| Storage Temperature |
−40°C to +85°C |
| Shock Resistance |
10 g, ½‑sine, 11 ms |
| Vibration |
Meets DeltaV M‑series industrial vibration criteria |
| Airborne Contaminants |
Conforms to ISA‑S71.04 G3 requirements |
Mechanical Data
| Parameter |
Specification |
| Dimensions |
16.8 × 4.2 × 6.8 cm |
| Weight |
0.2 kg |
| Mounting |
DeltaV M‑series carrier base |
| Country of Origin |
USA |
Logistics
| Parameter |
Specification |
| Condition |
Brand New |
| Availability |
In Stock |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The KJ4006X1‑BF1 (12P4728X052) SE4001S2T2B4 terminal block is engineered to maintain stable analog input acquisition in mission‑critical DCS environments. Its redundant design ensures uninterrupted operation even in the event of a single‑path failure. Each channel is optimized for low‑noise current loop measurement, enabling accurate process feedback for control loops.
Advanced onboard diagnostics continuously evaluate channel integrity, power conditions, and wiring status. These features help operators identify abnormal conditions early, reducing troubleshooting time and preventing unplanned shutdowns.
The module’s rugged construction and wide thermal tolerance make it suitable for oil and gas, petrochemical, power generation, and other heavy‑duty applications where reliability is essential.
Application Scenarios
-
Distributed Control Systems (DCS) requiring redundant analog input
-
Process plants with high uptime requirements
-
Harsh‑environment installations with extreme temperature exposure
-
Systems requiring precise current loop measurement
-
DeltaV modernization or replacement projects
FAQ
Q: Is this module backward‑compatible with earlier DeltaV I/O carriers? A: Yes. It is designed for M‑series carriers and maintains compatibility with standard DeltaV wiring practices.
Q: Can the module operate without redundancy? A: It can function in non‑redundant mode, but full reliability benefits are achieved only with redundant pairing.
Q: Does the module require special configuration in DeltaV software? A: No. It is recognized natively by DeltaV, and configuration is performed through standard AI channel setup menus.
