Description
Overview
The Emerson KJ4001X1‑NA1 (12P3373X032) is a Horizontal LocalBus Dual‑Right Cable Extender designed for DeltaV™ M‑Series I/O architectures. It enables right‑side LocalBus expansion, allowing additional I/O carriers to be connected while maintaining stable and reliable communication across the subsystem.
Functional Characteristics
This extender module supports high‑integrity LocalBus signal transmission, ensuring that communication between I/O carriers remains consistent even as system layouts grow in size or complexity. Its electrical design minimizes signal degradation, making it suitable for large‑scale distributed control system installations.
The KJ4001X1‑NA1 (12P3373X032) is built with durable materials and engineered for long‑term operation in industrial environments. Its compact form factor simplifies installation in tight cabinet spaces, while its mechanical robustness ensures dependable performance under vibration, temperature variations, and continuous system operation.
Technical Specifications
| Parameter |
Specification |
| Model |
KJ4001X1‑NA1 |
| Part Number |
12P3373X032 |
| Product Type |
Horizontal LocalBus Dual‑Right Cable Extender |
| System Platform |
DeltaV™ M‑Series I/O Subsystem |
| Function |
Extends LocalBus communication to additional right‑side carriers |
| Dimensions |
16.6 × 4.5 × 6.2 cm |
| Weight |
0.18 kg |
| Operating Environment |
Industrial‑grade, vibration‑resistant |
| Country of Origin |
USA |
| HS Code |
8537101190 |
| System Type |
DCS |
| Availability |
In stock |
Performance Description
The extender ensures reliable LocalBus communication across multiple I/O carriers, supporting system scalability without requiring major cabinet redesign. Its electrical characteristics support stable high‑speed data transfer, while its lightweight construction allows easy handling during installation or system upgrades.
The KJ4001X1‑NA1 (12P3373X032) integrates seamlessly with DeltaV M‑Series hardware, making it a dependable choice for expanding existing systems or integrating new I/O segments into distributed control architectures.
Application Scenarios
-
Expansion of DeltaV M‑Series I/O carriers
-
Distributed control system cabinet layout optimization
-
Large‑scale process automation requiring extended LocalBus communication
-
Modernization of legacy DeltaV installations
-
Industrial environments with strict space and wiring constraints
FAQ
Q: Is this extender compatible with left‑side LocalBus connections? A: No, this model is specifically designed for right‑side LocalBus extension.
Q: Does the extender require additional power modules? A: Power requirements depend on the number of carriers added; the extender itself does not significantly affect power consumption.
Q: Can it be used with all DeltaV M‑Series I/O types? A: Yes, it supports standard M‑Series I/O carriers within the LocalBus architecture.
