Description
Product Overview
The EMERSON KJ3241X1-BA1 12P2506X052 Interface Card is a Fieldbus H1 communication module designed for DeltaV™ distributed control systems. With dual-channel redundancy, it ensures continuous communication even during single-channel failures. Compact dimensions of 4.2 × 12.5 × 10.4 cm and a lightweight 0.1 kg design make it suitable for mission-critical installations in oil, gas, chemical, and power generation facilities.
Technical Specifications
| Parameter |
Value |
| Model Number |
KJ3241X1-BA1 12P2506X052 |
| Module Type |
Interface Card |
| Manufacturer |
EMERSON |
| Product Series |
DeltaV™ M-series I/O Subsystem |
| Condition |
Brand New |
| Dimensions |
4.2 × 12.5 × 10.4 cm |
| Weight |
0.1 kg |
| HS Code |
8537101190 |
| System |
DCS |
| Communication Service |
Ethernet Router |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| Lead Time |
In Stock |
| Status |
Discontinued (Dec 31, 2018) |
| Voltage Range |
9–32 VDC |
| Temperature Range |
-40°C to +70°C |
| Mounting Type |
DIN Rail |
| Certifications |
Intrinsic Safety, Hazardous Area |
| Redundancy |
Dual-Channel H1 Segment |
Functional Description
The KJ3241X1-BA1 12P2506X052 Interface Card delivers robust signal integrity and noise immunity in challenging electrical environments. Its rotary keying system prevents incorrect mating between I/O cards and terminal blocks, ensuring system safety. The module withstands vibration, humidity, and airborne contaminants, while its redundant architecture minimizes downtime risks.
Applications and Compatibility
The KJ3241X1-BA1 12P2506X052 integrates seamlessly with Emerson DeltaV systems, supporting predictive maintenance and centralized diagnostics. It suits industries such as oil and gas, petrochemical, and power generation, where reliable communication directly impacts operational safety. Compatibility with Foundation Fieldbus networks ensures flexible deployment in both greenfield projects and system upgrades.
