Product Description
Overview
The KJ3102X1-BA1 (12P2093X132) is a high-performance Redundant High-Speed Pulse Input Card for the Emerson DeltaV™ Series 2 Distributed Control System (DCS). It is engineered to capture high-frequency pulse signals with precision, making it ideal for applications such as turbine speed monitoring, flow measurement, and other pulse-based instrumentation. Its redundant design ensures continuous operation in critical process environments.
Key Features
-
High-Speed Pulse Processing: Handles inputs up to 50 kHz, providing accurate frequency and totalization measurement.
-
Redundancy and Failover: When paired with an identical module, it provides seamless failover within milliseconds to maintain uninterrupted process control.
-
Hot-Swappable: Can be safely replaced without shutting down the DeltaV system in non-hazardous environments.
-
Versatile Signal Compatibility: Accepts dry contacts, voltage pulses, and specialized transmitters with programmable filtering to prevent false counts.
-
Channel-Level Diagnostics: Monitors each input channel for open circuits, short circuits, and general health, reporting status to the DeltaV controller.
-
Robust Industrial Design: Supports operation from -40°C to 70°C, with storage up to 85°C, and humidity tolerance from 5% to 95% non-condensing.
Technical Specifications
| Feature |
Specification |
| Model Number |
KJ3102X1-BA1 / 12P2093X132 |
| Input Channels |
4 Isolated Channels |
| Max Pulse Frequency |
50 kHz |
| Input Type |
Pulse, Frequency, Totalization |
| Input Voltage |
24 VDC |
| Input Current |
80 mA |
| Output Voltage |
24 VDC |
| Output Current |
1.2 A |
| Isolation |
Channel-to-Channel and Channel-to-System |
| Operating Temperature |
-40°C to 70°C |
| Storage Temperature |
-40°C to 85°C |
| Humidity |
5–95% Non-Condensing |
| Dimensions |
12.5 cm × 7.5 cm × 2.5 cm |
Applications
-
Turbine and Motor Speed Monitoring: Captures high-speed rotational signals with minimal latency.
-
Flow Metering: Provides precise pulse counting for accurate fluid measurement.
-
Redundant Process Control Systems: Maintains data integrity during module or system faults.
Installation Notes
-
Refer to the product label for serial number and manufacture date.
-
Follow the DeltaV Zone 2 hazardous area installation guidelines (document 12P2046).
-
Do not remove or insert the card while system power is energized in hazardous zones.
-
Ensure network connections do not exceed 60 VAC or 75 VDC to prevent equipment damage.
FAQ
Q: Can the KJ3102X1-BA1 be used in hazardous areas?
A: Yes, but it must be installed according to Zone 2 guidelines in the DeltaV installation manual.
Q: How fast can this module count pulses?
A: The module can process pulses up to 50 kHz with high precision.
Q: What happens if one card fails in a redundant pair?
A: The standby card takes over immediately, ensuring uninterrupted process measurement.
