Product Description
Overview
The PR6424/000-010 from Emerson Epro is a 16 mm eddy current sensor engineered for high-precision vibration and displacement monitoring in rotating machinery and industrial equipment. This sensor provides reliable, stable measurements, making it suitable for predictive maintenance and condition monitoring systems.
Key Technical Specifications
Dynamic Performance
-
Sensitivity/Linearity: 4 V/mm (101.6 mV/mil), linearity error ≤ ±1.5%
-
Nominal Air Gap (Center): 2.7 mm
-
Long-Term Drift: <0.3%
-
Static Measurement Range: ±2.0 mm (±0.079 in)
-
Dynamic Measurement Range: 0–1,000 μm (0–0.039 in)
Mechanical Characteristics
-
Sleeve Thread: M18 x 1.5
-
Sensor Length Options: 40, 50, 60, 70, 80, 90, 100, 150, 200, 250, 290 mm (length = x + 12.5 mm formula)
-
Cable: Optional armored cable; standard cable included
-
Cable Length Options: 4 m, 5 m, 8 m, 10 m
-
Cable Connector: LEMO type
Applications
Ideal for vibration analysis, shaft displacement monitoring, and machine condition assessment in pumps, turbines, motors, and other rotating machinery. Suitable for both industrial plants and laboratory testing setups.
FAQ
Q: What is the maximum dynamic measurement range of this sensor?
A: The dynamic range extends up to 1,000 μm (0.039 in), optimized for high-frequency vibration detection.
Q: Can the sensor be used in high-temperature environments?
A: The sensor supports standard industrial temperatures; for high-temperature applications, consult Emerson Epro specifications for extended ranges.
Q: Are there alternatives within the same series?
A: The PR6420 series offers similar performance with varied measurement ranges and sensitivity ratings for specific industrial needs.
