Description

Product Description

Overview
The MMS3120/022-000 is a high-performance dual-channel vibration monitoring module from Epro, part of the Emerson MMS3000 series. Designed for continuous condition monitoring of rotating machinery, it delivers precise and reliable bearing vibration measurements using both electrodynamic and piezoelectric sensing technologies. This module is ideal for applications requiring accurate vibration trending and alarm functions in protection and predictive maintenance systems.

Measurement Capabilities
The transmitter captures signals from two independent vibration channels, allowing simultaneous monitoring of separate bearing locations. It supports multiple vibration metrics, including velocity, acceleration, and peak displacement. Advanced digital signal processing ensures stable and accurate readings even under fluctuating operational conditions.

Technical Specifications

Model: MMS3120/022-000
Manufacturer: Epro (Emerson MMS3000 Series)
Product Type: Dual Channel Bearing Vibration Transmitter

Measurement Inputs:

• Two independent vibration channels

• Compatible with electrodynamic velocity sensors (PR9268 series)

• Compatible with piezoelectric accelerometers

Measured Parameters:

• Vibration velocity

• Vibration acceleration

• Peak displacement

Output Signals:

• Configurable analog outputs (0/4–20 mA)

• Multiple programmable relay/function outputs

Power Supply: Dual redundant 24 VDC inputs

Signal Processing: Microcontroller-based with digital filtering, diagnostics, and signal integrity checks

Diagnostics: Continuous sensor monitoring, internal system supervision, and fault detection

Mechanical Data:

• Dimensions: 127.5 × 125.75 × 80 mm

• Weight: 1.3 kg

• Mounting: Standard DIN-rail or panel installation

Applications

• Continuous monitoring of industrial rotating equipment

• Bearing protection and predictive maintenance systems

• Turbines, pumps, compressors, and motors

FAQ
Q: Can it support multiple sensor types on the same channel?
A: Yes, each channel can be configured for either an electrodynamic or piezoelectric sensor.

Q: What is the maximum analog output configuration?
A: Each channel provides configurable 0–20 mA or 4–20 mA outputs, adaptable to control systems.

Q: How does it perform under variable load conditions?
A: Advanced digital filtering ensures stable readings despite load fluctuations or transient vibrations.

Similar Models Comparison

• MMS3120/021-000: Single-channel variant for simpler monitoring setups

• MMS3120/023-000: Dual-channel with extended temperature tolerance and additional diagnostics

Specifications

• Brand: EMERSON

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
