Product Overview
The VE4005S2B1 from Emerson is an 8-channel termination block engineered for 4-20mA HART I/O cards in DeltaV automation systems. It provides a secure and precise interface for field signals, ensuring accurate data transmission to controllers and minimizing signal errors in demanding industrial environments.
Key Features:
-
8-Channel Support: Compatible with 8-channel 4-20mA HART input/output cards
-
Unique Keying System: Dual keying posts prevent incorrect installation, each with six positions labeled A-F and 1-6
-
I/O Terminal Block Variants:
-
Standard I/O Terminal Block
-
Fused I/O Terminal Block for additional channel protection
-
4-Wire I/O Terminal Block for enhanced signal integrity
-
Compliance & Certifications: CE, FM3600/3611, CSA C22.2 No.213/1010-1, ATEX, IEC-Ex, Marine Certificates (IACS E10, ABS, DNV)
-
Hazardous Area Ratings:
-
FM (USA) Class I, Division 2, Groups A-D, T4
-
cFM (Canada) Class I, Division 2, Groups A-D, T4
-
ATEX & IEC-Ex Zone 2 approvals for gas and explosive atmospheres
Technical Specifications
| Feature |
Specification |
| Model / Part Number |
VE4005S2B1 |
| Channel Configuration |
8 Channels for 4-20mA HART signals |
| Keying Mechanism |
Dual posts, 6 positions (A-F, 1-6) to prevent misinstallation |
| Compatible I/O Blocks |
Standard, Fused, 4-Wire |
| Environmental Rating |
Suitable for hazardous and marine environments |
| Certifications |
CE, FM, CSA, ATEX, IEC-Ex, IACS E10, ABS, DNV |
| Hazardous Area Classifications |
FM USA: Class I Div 2, Groups A-D, T4; ATEX II3G Exec IICT4Gc; IEC-Ex II3G Exec IICT4Gc |
Performance Highlights
Reliable Signal Interface: Ensures precise connection of field devices to DeltaV I/O cards without data loss.
Installation Safety: Unique keying system prevents incorrect card insertion, reducing risk of wiring errors.
Versatile Configurations: Supports standard, fused, or 4-wire I/O blocks for different operational requirements.
Hazardous Area Ready: Certified for Class I, Division 2 and Zone 2 installations, suitable for chemical, offshore, and process environments.
Applications
-
4-20mA HART signal acquisition for DeltaV S-series systems
-
Industrial process monitoring in hazardous areas
-
Marine and offshore control systems requiring certified terminal blocks
FAQ
Q: Can this terminal block support fused I/O protection?
A: Yes, the VE4005S2B1 is compatible with fused I/O blocks for individual channel protection.
Q: How does the keying system prevent misinstallation?
A: Two rotating key posts with six defined positions prevent incorrect card insertion, ensuring accurate alignment.
Q: Is it suitable for marine applications?
A: Yes, it holds ABS, DNV, and IACS E10 marine certificates for offshore use.
Q: Which DeltaV cards are compatible?
A: Specifically keyed for 8-channel 4-20mA HART I/O cards (Key: A1).
