Description
Overview
The Emerson DeltaV KL3101X1-LS1 is an 8-channel analog input card engineered for DeltaV Distributed Control Systems (DCS). It interfaces with field-mounted transmitters, capturing 4-20 mA signals and supporting HART communication for digital diagnostics and secondary variable monitoring. Part of the S-Series “Electronic Marshalling” hardware, this module combines high-density input, precision conversion, and robust industrial resilience.
This module is designed for standard process control environments, providing reliable performance and seamless integration in high-density I/O cabinets.
Technical Features
HART Integration
-
Supports digital pass-through of HART data alongside analog signals
-
Enables device health monitoring and remote calibration via AMS Device Manager
-
Facilitates predictive maintenance without additional wiring
High-Density Design
-
8 analog inputs per card to maximize cabinet space
-
Low power consumption for efficient thermal management
-
Compact form factor simplifies installation and expansion
Reliability and Protection
-
Galvanic isolation safeguards controller electronics from field surges
-
Conformal coating per ISA-71.04 Class G3 protects against dust, moisture, and corrosive atmospheres
-
Built for continuous operation in harsh industrial environments
Hot-Swappable Operation
Technical Specifications
| Feature |
Specification |
| Input Channels |
8 Analog Channels |
| Signal Type |
4-20 mA DC |
| HART Support |
Digital Pass-Through |
| A/D Resolution |
16-bit |
| Sampling Interval |
100 ms per 8 channels |
| Accuracy |
≤0.1% of Span |
| Operating Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Protection |
Conformal coating G3, galvanic isolation |
Operational Advantages
-
Simplifies wiring by eliminating external HART multiplexers
-
Enhances proactive diagnostics for early detection of device faults
-
Automatically recognized by DeltaV software, reducing commissioning time
-
Supports flexible system expansion in S-Series hardware setups
Applications
-
Standard process control in chemical, pharmaceutical, and oil & gas industries
-
High-density analog signal collection in DeltaV S-Series cabinets
-
Remote monitoring and predictive maintenance using HART-enabled devices
FAQ
Q: Can the KL3101X1-LS1 be installed or removed while the system is running?
A: Yes, it supports hot-swappable operation, allowing replacement without shutting down other system components.
Q: Does the module require field calibration?
A: No. The module is factory-calibrated and contains no user-serviceable parts.
Q: Which DeltaV systems are compatible?
A: Compatible with DeltaV S-Series controllers and carriers; verify system version before installation.
Q: What environments can it operate in safely?
A: Rated for standard industrial environments with temperature extremes from -40°C to 70°C and protection against dust and moisture (G3 conformal coating).
