The Emerson DeltaV KJ4010X1-BG1 is an advanced S-series MX Controller designed for the DeltaV System 8000 platform. As a high-capacity processing unit, it delivers superior memory and computational performance compared to the MQ series, making it suitable for complex and large-scale process control operations. This controller manages I/O communication, executes real-time control strategies, and integrates seamlessly into S-series horizontal carriers with plug-and-play simplicity.

Key Features

Enhanced Processing and Capacity

• Increased memory and processing resources for handling complex control strategies

• Supports up to 1,500 I/O points depending on software license, accommodating large industrial systems

High-Speed Execution

• Rapid processing of PID loops, advanced math, and logic functions

• Optimized for low-latency communication across the DeltaV Control Network for real-time updates

Availability and Redundancy

• Native 1:1 redundancy allows seamless failover without disrupting control

• Supports online software upgrades and hot-swapping of the hardware

Modern Design and Safety

• Electronic keying prevents incorrect module installation

• Passive cooling ensures reliable operation without moving parts that could fail

Diagnostics and Cybersecurity

• Continuous self-checks of CPU, memory, and communication integrity

• Embedded firewall protects control logic from network threats

Environmental Resilience

• Hazardous area certified: II 3 G, Nemko No. 02ATEX431U, EEx nA IIC T4

• Shock: 10 g, ½ sine wave for 11 ms; Vibration: 1 mm p-p (5–16 Hz), 0.5 g (16–150 Hz)

• Airborne contaminants: ISA-S71.04-1985 Class G3; Humidity: 5–95% non-condensing

• IP20 rated enclosure

Technical Specifications

Feature	Specification
Model Type	S-Series MX Controller
Series	S-Series (System 8000)
Input Power	24 VDC ±10%
Typical Power Draw	0.25 A at 24 VDC
LocalBus Power	12.6 VDC at 8 A
I/O Capacity	Up to 1,500 points
Operating Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5–95%, non-condensing
Shock Resistance	10 g, ½ sine wave, 11 ms
Vibration Resistance	1 mm p-p (5–16 Hz), 0.5 g (16–150 Hz)
Certifications	II 3 G, Nemko No. 02ATEX431U, EEx nA IIC T4
Mounting	DeltaV S-series Horizontal Carrier
IP Rating	IP20

Applications

• Plant-wide process control for large reactors, distillation columns, and multi-unit operations

• High-complexity automation systems requiring high I/O capacity and redundant processing

• Hazardous environments requiring certified safety and reliability

FAQ

Q: How does the MX controller differ from the MQ series?
A: The MX (KJ4010X1-BG1) has double the memory and I/O capacity, supporting up to 1,500 points, while MQ supports fewer points.

Q: Can the module be hot-swapped?
A: Yes, the controller supports hot-swapping and online software upgrades without stopping the process.

Q: What environmental certifications does this unit have?
A: Certified for hazardous areas: II 3 G, Nemko No. 02ATEX431U, EEx nA IIC T4, with shock, vibration, and contaminant resistance.

Q: Are there any installation warnings?
A: Always de-energize the system before removing or installing the module or LocalBus Extenders. Maximum cable length is 6.5 meters.
