The Emerson DeltaV KJ3006X1-BA1 is a high-performance system power supply designed for the DeltaV M-Series Distributed Control System. This module delivers stable and regulated voltages to the local bus, powering I/O interface carriers and attached modules while ensuring reliable communication across the backplane. Its design emphasizes redundancy, robust diagnostics, and durability for industrial environments.

Key Features

Redundancy and Reliability

• Supports dual redundant configurations for uninterrupted operation

• Hot-swappable capability allows maintenance or replacement without system downtime

Power Management

• Provides regulated 12V DC and 5V DC outputs to the local bus

• Includes overload protection to prevent damage from short circuits or excessive current

Monitoring and Diagnostics

• Front-panel LED indicators for Power and Error

• DeltaV software integration offers real-time system alerts

Environmental and Mechanical Design

• Industrial-grade construction tolerates high temperature, vibration, and contaminants

• Compact footprint fits 2-wide or 4-wide DeltaV carriers efficiently

Technical Specifications

Feature	Specification
Input Voltage	24 VDC ±10%
Output Voltage	Local Bus: 12 VDC / 5 VDC
Max Output Current	8 A (approx., depending on load)
Module Type	M-Series System Power Supply
Operating Temperature	-40°C to 70°C
Relative Humidity	5% to 95%, non-condensing
Environmental Resistance	Shock: 10 g, 11 ms half-sine; Vibration: 1 mm p-p (5–16 Hz), 0.5 g (16–150 Hz); Airborne Contaminants: ISA-S71.04 G3
Certifications	Class I, Division 2, Groups A–D; T4 at Ta = 70°C; ATEX/IECEx Zone 2
Mounting	Occupies one slot on DeltaV Carrier
Dimensions	10.4 × 3.0 × 10.9 cm
Weight	0.14 kg

Applications

• DeltaV M-Series DCS local bus power supply

• Critical process automation requiring high availability

• Hazardous or vibration-prone environments with strict electrical safety standards

FAQ

Q: Can this module be used in a redundant setup?
A: Yes, it supports dual redundant operation for seamless system reliability.

Q: What happens if the module fails during operation?
A: In redundant setups, the secondary module takes over instantly, maintaining system operation.

Q: Is it safe to replace the module while the system is running?
A: Yes, the KJ3006X1-BA1 is hot-swappable.

Q: Does it support HART communication?
A: Yes, it provides 24V DC field circuit power compatible with HART devices.

Specifications

• Brand: EMERSON

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
