Overview
The CON021+PR6424/013-030 from Emerson is a high-precision eddy current proximity sensor designed for non-contact measurement of displacement and vibration in critical rotating equipment. It is ideal for monitoring shaft position, eccentricity, and rotational speed in turbines, compressors, pumps, and other industrial machinery.
Key Features and Technical Specifications
| Parameter |
Specification |
| Model |
CON021+PR6424/013-030 |
| Sensor Type |
Eddy Current Proximity Sensor |
| Probe Head Diameter |
16 mm |
| Measurement Range |
±2.0 mm dynamic, 0–1000 µm static |
| Sensitivity / Linearity |
4 V/mm (101.6 mV/mil), ≤ ±1.5% |
| Nominal Air Gap |
~2.7 mm |
| Frequency Response |
DC to 20 kHz |
| Target Material |
Ferromagnetic steel (42CrMo4 standard) |
| Maximum Surface Speed |
2,500 m/s |
| Minimum Shaft Diameter |
≥ 80 mm |
| Operating Temperature |
-35°C to +150°C (sensor head) |
| Storage Temperature |
-40°C to +200°C |
| Pressure Resistance |
Up to 10,000 hPa (145 psi) |
| Housing Material |
Stainless steel, corrosion-resistant |
| Cable Type |
Integrated coaxial cable, 3 m length (suffix /013-030) |
| Protection Rating |
IP65 or higher (depending on installation) |
| Weight |
~0.32 kg |
Applications
The CON021+PR6424/013-030 is engineered for demanding environments where reliable measurement of shaft dynamics is critical. Typical applications include:
FAQ
Q: Can this sensor measure on non-ferromagnetic shafts?
A: The sensor is optimized for ferromagnetic materials. For non-ferromagnetic targets, alternative models or adapters may be required.
Q: What is the maximum cable length for reliable readings?
A: The integrated coaxial cable is 3 meters. Longer distances may require signal conditioning.
Q: How does this model compare to CON021+PR6424/013-025?
A: Both share similar dynamic measurement ranges, but the /013-030 version supports slightly higher pressure and temperature tolerances, making it suitable for more demanding industrial applications.
