The CON021 | 913-040 is a high-performance signal converter designed to interface with the PR6424/000-000 eddy current displacement sensor. This assembly provides precise, non-contact measurement of radial and axial motion in high-speed rotating machinery, including turbines, compressors, and industrial pumps. Operating on eddy current principles, the system detects minute changes in shaft position and converts these signals into standardized analog voltage outputs suitable for machine monitoring systems or distributed control systems.
The PR6424/000-000 sensor is engineered for extreme industrial environments, offering robust resistance to temperature fluctuations, pressure, and exposure to oils or chemicals. Together, the converter and probe provide a reliable, high-resolution measurement solution for vibration and displacement monitoring.
Key Technical Features
High Accuracy and Linearity
Non-Contact Operation
-
Measures shaft vibration and position without physical contact, reducing wear and maintenance.
-
Ideal for continuous operation in high-speed machinery.
Environmental Robustness
-
Operating temperature: Probe -35°C to +150°C, Converter -20°C to +80°C
-
Resistant to industrial lubricants, coolants, and chemical exposure.
-
Probe tip designed for high-pressure industrial environments.
Dynamic and Static Measurement Capability
Standardized Industrial Output
-
Analog voltage output proportional to gap (e.g., 0 to -20V or -2V to -18V).
-
Compatible with Emerson MMS, DCS, and other control systems.
Technical Specifications Table
| Feature |
Specification |
| Sensor Type |
Eddy Current / Non-Contact |
| Measurement Range |
4.0 mm (typical for PR6424) |
| Output Signal |
Analog Voltage, proportional to gap |
| Linearity |
< ±1% full scale |
| Frequency Response |
0–10 kHz typical |
| Operating Temperature |
Probe: -35°C to +150°C, Converter: -20°C to +80°C |
| Mechanical Protection |
IP65–IP67 (sensor tip depending on mounting) |
| Application |
Radial vibration, axial thrust, shaft eccentricity |
Applications
-
Monitoring turbine and compressor shafts in power plants.
-
Detecting pump shaft misalignment and imbalance.
-
Predictive maintenance of high-speed rotating equipment.
-
Integration into machine condition monitoring and control systems.
FAQ
Q: Can the sensor measure both vibration and displacement simultaneously?
A: Yes, the PR6424 probe captures dynamic radial vibrations and static axial displacement concurrently.
Q: What environments can the sensor withstand?
A: The probe is engineered for high temperature, oil, and chemical exposure, suitable for harsh industrial machinery housings.
Q: What type of output does the converter provide?
A: The CON021 outputs a standardized analog voltage proportional to shaft displacement, compatible with MMS or DCS systems.
Q: Are there alternative models for higher temperature ranges?
A: Emerson offers variants in the PR64xx series designed for extreme heat or pressure conditions.
