Description
Product Description
Overview
The CON010 (PR6424/010-040) from Emerson offers a fully integrated solution for precise vibration and shaft displacement monitoring. This kit combines the high-accuracy CON010 eddy current sensor module with the PR6424/010-040 proximity probe, delivering reliable diagnostics and protection for rotating machinery in challenging industrial environments.
Key Features
-
Integrated Sensor Solution: Combines module and probe for comprehensive vibration and shaft displacement monitoring.
-
High Precision Measurement: Supports exact detection of shaft movement and vibration using eddy current technology.
-
Compact Probe Design: 40 mm probe length ensures suitability for installations with limited space.
-
Robust and Durable: Designed to withstand mechanical shock, vibration, and airborne contaminants.
-
Seamless System Compatibility: Fully compatible with Emerson EPRO monitoring platforms for continuous operation in critical systems.
Technical Specifications
| Parameter |
Specification |
| Module Model |
CON010 Eddy Current Sensor Module |
| Probe Model |
PR6424/010-040 Proximity Probe |
| Probe Length |
40 mm |
| Measurement Type |
Shaft displacement and vibration via eddy current |
| Input Type |
Eddy current proximity probe |
| System Compatibility |
Emerson EPRO monitoring systems |
| Voltage Supply |
24 VDC (system-dependent) |
| Operating Temperature |
-40°C to +70°C |
| Shock Resistance |
10 g, half-sine wave, 11 ms duration |
| Vibration Endurance |
1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz) |
| Airborne Contaminants |
ISA-S71.04-1985, Class G3 |
| Relative Humidity |
5–95%, non-condensing |
| Protection Rating |
IP20 |
Applications
Ideal for use in turbines, compressors, pumps, and other rotating machinery requiring continuous monitoring in industrial settings, including petrochemical, power generation, and heavy manufacturing.
FAQ
Q: Can this sensor kit be integrated with third-party monitoring systems?
A: The CON010 (PR6424/010-040) is optimized for Emerson EPRO platforms. Third-party integration may require signal conditioning.
Q: Is the probe suitable for high-temperature environments?
A: The probe operates reliably from -40°C to +70°C. For higher temperatures, consult Emerson specifications.
Q: How does this model differ from CON011?
A: Compared to CON011, the CON010 offers a more compact probe and slightly higher vibration resistance, making it suitable for confined installations and higher shock environments.
