Description

Overview

The Emerson 5X00225G01 Ovation Controller Base integrates field wiring with I/O modules through a robust printed circuit board and precision-molded housing. It supports dual I/O module sets and ensures low-impedance grounding for stable signal transmission. This unit powers connected modules and simplifies field signal routing for industrial automation systems.

Key Features

• Supports two I/O module sets with field wiring

• Provides low-impedance earth ground connection

• Enables direct power delivery to I/O modules

• Compact footprint with fanless operation

• Interfaces with Ovation and WDPF I/O systems

• Integrates virtual I/O for Ethernet-based OEM systems

• Stores application data and tuning constants in non-volatile memory

• Offers 1 ms resolution for event sequencing

• Complies with IEC 61131-3 standards

• Certified to Achilles Level 1 for cybersecurity

Technical Specifications

Specifications

• Dimensions: 24 cm × 15 cm × 10 cm
• Brand: Emerson

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
