Product Description
Overview
The Emerson 396563-06-6 is an 8-channel analog input/output External Terminal Block (ETB) engineered for DeltaV Distributed Control Systems. Serving as the physical interface between field devices and DeltaV I/O modules, it supports precise analog signal transmission while safeguarding system components with integrated channel protection. Designed for industrial environments, it provides robust performance in demanding temperature and electrical conditions.
Key Technical Features
Signal Protection and Reliability
-
Each channel includes a dedicated 250 mA fuse to prevent individual field faults from affecting the entire I/O module.
-
Current limiting circuitry reduces the risk of damage during transient voltage events.
Signal Integrity
Ease of Installation and Maintenance
System Efficiency
Technical Specifications
| Feature |
Specification |
| Number of Channels |
8 Channels |
| Signal Type |
Analog Input / Analog Output (2-wire) |
| Field Termination |
Screw Terminals |
| System Termination |
Mass Connect to DeltaV I/O |
| Channel Protection |
250 mA Fuse per Channel |
| Mounting |
35 mm DIN Rail |
| Operating Temperature |
-40°C to +70°C |
| Nominal Voltage |
24 VDC |
| Dimensions |
4.7" x 3.5" x 1.8" |
| Weight |
0.25 lbs |
Applications
Ideal for loop-powered analog devices, the 396563-06-6 is commonly deployed in chemical, petrochemical, and power generation facilities where field device reliability and protection are critical.
FAQ
Q: Can this terminal block be used with both M-series and S-series DeltaV I/O modules?
A: Yes, the 396563-06-6 is fully compatible with both M-series and S-series modules.
Q: What type of signals does it support?
A: It supports standard 2-wire analog input and output signals, typically 4–20 mA loops.
Q: Does it provide individual channel protection?
A: Yes, each channel has its own 250 mA fuse to isolate faults.
