Overview
The KJ3208X1-BA1 is an 8-channel isolated digital output module from the DeltaV M-Series, designed for process control in hazardous environments. It delivers reliable channel isolation, flexible local bus power, and ensures high availability and safety in industrial control systems.
Certifications & Explosion Protection
-
ATEX: II 3G Ex nA IIC Gc (Certificate: FM12ATEX0090U)
-
IECEx: IECEx FMG 12.0035U
The module meets international explosion-proof standards, enabling safe operation in gas-hazardous zones.
Power & Interface Specifications
-
Local Bus Power: 12 VDC, 150 mA
-
Field Circuit Output: 60 VDC, up to 1 A per channel
-
Channel Count: 8
-
Isolation: Channel-to-channel isolation minimizes signal interference
Installation & Operation Guidelines
-
Modules must not be inserted or removed in hazardous areas while system power is on. Only one module should be replaced at a time.
-
Non-sparking field circuits must be de-energized prior to insertion/removal.
-
A rotary keying system ensures correct matching between I/O cards and terminal blocks.
-
The module contains no user-serviceable parts and does not require calibration. Disassembly is prohibited.
Applications
Ideal for Zone 2 hazardous areas in oil & gas, chemical processing, pharmaceuticals, and other industrial automation environments. Can be integrated with other DeltaV M-Series modules for highly reliable distributed control systems.
FAQ
Q: Does this module require on-site calibration?
A: No, the module is factory-calibrated and requires no user calibration.
Q: Can the module be inserted while the system is powered?
A: Only in non-hazardous areas and one module at a time.
Q: What environmental stresses can it withstand?
A: Reliable operation from -40°C to +70°C, resistant to vibration and shock, compliant with ISA-S71.04 Class G3 air contaminant rating.
Q: Is it compatible with other DeltaV M-Series modules?
A: Yes, the rotary key ensures correct terminal block alignment for seamless integration.
Technical Specifications
| Parameter |
Specification |
| Module Model |
KJ3208X1-BA1 |
| Channel Count |
8 |
| Output Type |
24 VDC isolated digital output |
| Maximum Channel Current |
1 A |
| Local Bus Power |
12 VDC, 150 mA |
| Explosion Protection |
ATEX II 3G Ex nA IIC Gc, IECEx FMG 12.0035U |
| Operating Temperature |
-40°C to +70°C |
| Shock |
10g, half-sine, 11 ms |
| Vibration |
1 mm peak-to-peak (2–13.2 Hz), 0.7g (13.2–150 Hz) |
| Air Contaminant Rating |
ISA-S71.04 Class G3 |
| Relative Humidity |
5–95%, non-condensing |
| Protection Rating |
IP20, B5 |
