Schneider Electric BMEXBP0400 Rack Backplane Module

Configured for backplane signal distribution and Ethernet bus interconnection in Modicon X80 architectures, the Schneider Electric BMEXBP0400 (BMEXBP0400 Rack X80 - 4 slots - Ethernet backplane) provides direct physical/electrical execution. The module defines a 4-slot X80 rack segment integrating X bus and Ethernet backplane communication, enabling deterministic module-to-module data exchange between CPU, I/O, and power supply elements within the same rack structure.

Suffix Breakdown & Model Matrix

• BMEXBP: X80 Ethernet backplane rack family identifier
• 0400: 4-slot rack configuration

No additional functional suffix segmentation is defined for this catalog reference.

Hardware Specifications

Parameter	Specification
ModelBrand	Schneider Electric BMEXBP0400
Weight	0.705 kg
OperatingTemp	0 degC to 60 degC
PowerConsumption	2.8 W
Backplane Slots	4 slots (X bus + Ethernet)
Current Consumption	49 mA at 3.3 VDC, 118 mA at 24 VDC
Electrical Interface	XBE connector
Mounting Method	DIN rail, panel, plate (M6 / screw fixing)
Protection Class	IP20

Schneider Electric Backplane Bus Deterministic Communication Behavior

Within Modicon X80 systems, the BMEXBP0400 implements segmented backplane routing for X bus and Ethernet-enabled module communication. The rack design maintains deterministic frame propagation across installed CPU (BMEP58 series), power supply (BMXCPS), and I/O modules. Backplane timing integrity is dependent on slot adjacency and internal rack impedance matching, ensuring stable inter-module exchange without external cabling within the rack boundary. Firmware-level compatibility is aligned with X80 backplane arbitration rules and module discovery sequencing during system initialization.

Frequently Asked Questions

Q: Does BMEXBP0400 support hot-swap of modules in the rack?
A: Hot-swap capability depends on installed X80 modules and system configuration. The backplane itself provides passive connectivity without switching logic.

Q: What is the electrical load limitation on the backplane power distribution?
A: Backplane load is determined by cumulative module consumption across 3.3 VDC and 24 VDC rails within the rack power budget defined by the BMXCPS supply.

Q: Is Ethernet communication routed through the same backplane as X bus signals?
A: The rack supports combined X bus and Ethernet backplane architecture with logical separation at protocol level.

Field Installation Guidelines

Install the rack on a 35 mm DIN rail or rigid panel using four-point M6 or equivalent screw fixation. Ensure conductive grounding continuity between rack chassis and cabinet earth reference. Maintain minimum clearance for thermal dissipation across 0 to 60 degC ambient range. Avoid mechanical stress on XBE connector during module insertion. Shielded cabinet wiring practices should be applied for Ethernet segments to maintain signal integrity across adjacent X80 modules.
