Bently Nevada 86739-01 3500 Dual Vibration Monitor The Bently Nevada 86739-01, also cataloged as the 86739-01 Dual Vibration Monitor, operates...
Read more
The Bently Nevada 86739-01, also cataloged as the 86739-01 Dual Vibration Monitor, operates as a dedicated hardware component for vibration and position signal monitoring within the Bently Nevada 3500 Machinery Protection System.
Hardware Specifications
Parameter
Specification
Model
86739-01
Brand
Bently Nevada
Product Type
Dual Vibration Monitor
Series
3500
Origin
United States (USA)
Operating Temp
0 to 65 deg C
Storage Temp
-40 to 85 deg C
Power Consumption
Not specified in available documentation
Monitoring Function
Dual channel vibration monitoring
System Compatibility
Bently Nevada 3500 Machinery Protection System
Application Standard
Designed for API 670 machinery protection requirements
Rotor Dynamics and Vibration Signal Monitoring
The Bently Nevada 86739-01 monitors vibration signals from rotating machinery through dual measurement channels within the 3500 platform. The module processes vibration-related inputs and supports continuous online condition monitoring.
The monitor works with Bently Nevada transducer systems that use eddy-current probe scaling methods for shaft displacement measurement. Therefore, correct probe calibration and gap voltage validation are required to maintain accurate vibration measurement performance. Typical eddy-current systems use gap voltage targets near -10 VDC for valid probe operation.
In addition, the module supports rotor dynamics analysis by providing vibration data required for evaluating shaft movement, mechanical imbalance, misalignment, and other rotating equipment conditions. Signal processing design also considers cross-talk suppression between monitoring channels to reduce interference during multi-channel operation.
Frequently Asked Questions
Q: What function does the Bently Nevada 86739-01 provide in a 3500 system? A: The 86739-01 provides dual-channel vibration monitoring for machinery protection applications within the Bently Nevada 3500 system.
Q: Does the 86739-01 support eddy-current probe measurement systems? A: Yes. The module operates with Bently Nevada proximity measurement systems that use eddy-current probe scaling and gap voltage validation methods.
Q: What environmental temperature range applies to this monitor? A: The operating temperature range is 0 to 65 deg C, while the storage temperature range is -40 to 85 deg C.
Field Installation Guidelines
Install the 86739-01 module in a compatible Bently Nevada 3500 rack configuration according to the system installation manual.
Connect vibration transducer wiring using shielded instrumentation cables. Ground cable shields according to site grounding practices to minimize electrical noise coupling.
Keep vibration signal wiring separated from high-current power conductors and switching circuits. Verify sensor polarity, channel assignment, and probe calibration before placing the monitoring channel into service.
Confirm the eddy-current probe gap voltage before final commissioning. The measured signal should match the expected probe operating range and system configuration parameters.
Check rack power status, System Monitor communication, and channel configuration after installation. Perform functional verification using the configured vibration monitoring parameters before enabling machinery protection functions.
