Configured for system display data processing in the Bently Nevada 3500 Monitoring System, the Bently Nevada 3500/93 135799-02 (3500/93 Display Interface Module) provides direct physical and electrical execution for event and measurement data presentation.
Hardware Specifications
Parameter
Specification
Model
3500/93 135799-02
Brand
Bently Nevada
Product Type
Display Interface Module
Series
3500 Machinery Protection System
Origin
USA
Weight
0.82 kg
Dimensions
2.5 x 25 x 24 cm (estimated shipping size)
Operating Temp
-30 deg C to +65 deg C (-22 deg F to +150 deg F)
Storage Temp
-40 deg C to +85 deg C (-40 deg F to +185 deg F)
Humidity
95%, noncondensing
Compatible Options
A05 through A08 display options
Interface Function
System event list, alarm event list, channel and module data display
Rotor Monitoring Data Display Interface
The 3500/93 Display Interface Module provides the hardware interface for presenting monitoring information collected by the 3500 system rack. It processes display data associated with system events, alarm events, channel measurements, and module status information.
The module supports visualization of data from monitored channels, monitor modules, relay modules, Keyphasor modules, and tachometer modules. The interface structure allows operators to access vibration monitoring information generated by the Bently Nevada TSI architecture.
The module operates with Bently Nevada signal processing functions, including eddy-current probe scaling verification, gap voltage monitoring reference handling, rotor dynamics data presentation, and vibration channel status display. These functions support interpretation of machinery condition parameters generated by connected monitoring modules.
Frequently Asked Questions
Q: What data sources can the 3500/93 135799-02 display? A: The module displays system event lists, alarm event lists, channel data, monitor module information, relay module status, Keyphasor module data, and tachometer module data.
Q: Is the 3500/93 135799-02 a vibration input acquisition module? A: No. The module functions as a display interface component. Vibration signal acquisition and processing are performed by dedicated monitoring modules installed in the 3500 rack.
Q: What installation options are supported by this module? A: The 135799-02 version is specified for use with A05 through A08 display options within the Bently Nevada 3500 system configuration.
Field Installation Guidelines
Verify that the 3500 rack configuration supports the 3500/93 Display Interface Module before installation.
Install the module according to the designated rack slot assignment and system configuration documentation.
Maintain proper grounding practices for the rack enclosure and connected monitoring equipment.
Separate signal wiring from high-voltage power cables to reduce electrical interference.
Confirm connector seating and mechanical locking features before system startup.
Check display communication status after installation through the 3500 system interface.
