Product Description
The Bently Nevada 3500/22M 164466-01 Transient Data Interface (TDI) serves as the central communications and data acquisition gateway for the 3500 Machinery Protection System. It consolidates rack-level communication, configuration control, and high-resolution vibration data transfer into a single integrated module.
Functionally, this module replaces the legacy rack interface role while extending capability into advanced transient data capture, enabling detailed machinery behavior analysis during start-up, coast-down, and process disturbances. It is engineered for continuous integration with System 1 condition monitoring software.
Designed for reliability in critical rotating equipment environments, the module ensures that both static and dynamic machine data are reliably transmitted, stored, and synchronized across the monitoring architecture.
Technical Specifications
-
Model: 3500/22M
-
Part Number: 164466-01
-
Module Type: Transient Data Interface (TDI) / Rack Communication Gateway
-
System Compatibility: Bently Nevada 3500 Series Racks (3500/05 and variants)
-
Primary Function: Rack configuration management + high-speed machinery data interface
-
Data Types Supported:
-
Static process variables
-
Dynamic vibration waveforms
-
Transient event data (start-up / coast-down)
-
Alarm and system event logs
-
Communication Interfaces:
-
Ethernet 10/100 Base-T
-
USB Type-B service port
-
Protocols: Bently Nevada proprietary protocol, Modbus TCP (via gateway configuration)
-
Control Inputs: Rack reset input, OK relay status output
-
Front Panel Indicators: Power/OK status, TX/RX communication activity, configuration status, test mode indicator
-
Power Consumption: ~5–7 W (typical operating range depending on configuration)
-
Operating Temperature: -30°C to +65°C
-
Mounting Location: Slot 1 of 3500 rack (system dedicated position)
-
Configuration Storage: Non-volatile rack configuration memory for module interchange support
Key Functional Characteristics
-
Centralized communication bridge between rack hardware and System 1 software platform
-
Enables transient waveform capture during mechanical speed variation events
-
Maintains rack configuration integrity during module replacement or hot-swap events
-
Supports synchronized diagnostic data acquisition across multiple monitor modules
-
Provides diagnostic visibility into vibration trends, phase, and spectral behavior
Applications
-
Turbomachinery condition monitoring systems
-
Steam and gas turbine protection architectures
-
Compressor vibration diagnostics
-
Critical rotating equipment health management
-
Continuous plant-wide machinery protection systems
FAQ
Q1: Does the 3500/22M replace the rack interface module?
Yes. It integrates the functions of the legacy rack interface while adding transient data processing capability.
Q2: Can it capture startup vibration data?
Yes. It is specifically designed to capture high-resolution transient waveforms during speed changes.
Q3: Is System 1 software required?
It is fully optimized for System 1 integration, which is required for advanced diagnostic visualization and analytics.
