Description
Product Overview
The 3500/05-02-05-00-00-00 is a rack-based chassis unit within the Bently Nevada 3500 machinery protection platform, designed to host and interconnect condition monitoring modules in industrial environments. It functions as the structural and electrical backbone of the 3500 system, enabling centralized vibration monitoring, signal processing, and communication routing.
This configuration integrates rack mounting, system backplane architecture, and Ethernet-based communication support, making it suitable for advanced condition monitoring and predictive maintenance applications.
Technical Configuration Summary
This model is defined by the following system configuration:
-
Full integration into the 3500 system platform
-
Rack chassis architecture for PLC-style system deployment
-
Standard non-barrier backplane design
-
Active Ethernet router communication capability
-
Industrial-grade monitoring and protection framework
Mechanical & Physical Specifications
-
Product Type: PLC-style system rack chassis
-
Mounting orientation: Rack-based industrial enclosure
-
Dimensions: 48.2 × 28 × 26.5 cm
-
Weight: 5.95 kg
-
Condition: New unit
-
Origin: USA
-
Minimum order quantity: 1 unit
The chassis is designed for stable cabinet installation with optimized airflow and vibration resistance for continuous operation.
System Architecture & Functionality
The 3500/05-02-05-00-00-00 supports multi-channel condition monitoring and integrates with the broader 3500 protection system architecture.
Core functional capabilities include:
-
Multi-channel vibration data acquisition (system-level monitoring)
-
Signal processing for rotating machinery diagnostics
-
Early detection of imbalance, misalignment, and mechanical degradation
-
Integration with plant-wide control and monitoring systems
-
Standalone operation capability for local protection continuity
The system is designed to maintain monitoring integrity even under network interruption conditions.
Communication & Processing Capabilities
-
Built-in Ethernet routing functionality
-
Supports data exchange with plant control systems
-
Compatible with TSI (Turbine Supervisory Instrumentation) architecture
-
High-speed internal signal routing for monitoring modules
-
Stable communication under electrically noisy industrial environments
Monitoring & Protection Features
-
Continuous vibration trend analysis
-
Predictive failure detection based on condition patterns
-
High-resolution measurement processing (multi-channel architecture)
-
Electrical isolation for signal stability
-
Designed for long-term asset protection and reliability monitoring
Environmental & Operational Ratings
-
Designed for harsh industrial environments
-
Suitable for continuous duty operation
-
Resistant to vibration, EMI, and thermal cycling conditions
-
Supports installation in power generation and heavy process industries
Compliance & Classification
Application Areas
-
Power generation turbines and auxiliary systems
-
Oil and gas refining machinery
-
Large-scale rotating equipment monitoring
-
Industrial compressor and pump systems
-
Condition-based maintenance programs in critical infrastructure
FAQ
Q1: Is this unit a standalone PLC system?
It functions as a chassis-based monitoring platform within the Bently Nevada 3500 system and integrates with PLC/TSI environments.
Q2: Does it support Ethernet communication?
Yes, it includes integrated Ethernet routing capability for system-level communication.
Q3: Can it operate without a full system network?
Yes, it supports standalone operation for local monitoring and protection functions.
