Description

System Overview

The 3500/05-02-04-00-00-00 is a compact rack assembly within the Bently Nevada 3500 protection platform. It is engineered for installations where cabinet space is limited but full machinery protection functionality is still required. The unit integrates mechanical housing, electrical backplane routing, and modular power distribution in a reduced 7-slot configuration.

This mini rack maintains full compatibility with the 3500 system architecture while reducing footprint compared to standard 14-slot chassis designs.

Configuration Definition

This model is defined by the following structure:

• Mini rack chassis with 7 module positions

• 19-inch rack-mount installation format

• Standard non-barrier backplane architecture

• No internal isolation barriers included

• Standard finish configuration

The design supports compact system integration without compromising signal integrity or system reliability.

Mechanical Construction

• Rack type: Mini-size 3500 chassis

• Mounting style: Rack-mount (EIA 19-inch rails)

• Construction material: Industrial-grade aluminum alloy

• Approximate dimensions:

• Height: ~178 mm (7 in)

• Width: 305 mm (12 in)

• Depth: ~305 mm (12 in)

• Service access: Rear wiring access for rack-mounted cabinet installations

The reduced frame size is optimized for skid systems and compact enclosures.

Module Capacity & Layout

Internal slot structure supports essential system components:

• Dedicated slots for:

• Rack Interface Module (RIM)

• Power supply module

• Remaining slots available for:

• Vibration monitoring modules

• Relay modules

• Communication interface modules

Total usable capacity: 7 modules maximum

Electrical Architecture

• Backplane type: Standard non-barrier configuration

• Power input: Supports single or redundant power supply operation

• Internal buses:

• System communication data bus

• Relay output bus

• Keyphasor and transducer signal routing channels

• Full compatibility with standard Bently Nevada 3500 module range (within slot limitation)

• Designed for continuous machinery protection applications

Environmental Performance

• Operating temperature: –20°C to +65°C

• Storage temperature: –40°C to +85°C

• Relative humidity: up to 95% non-condensing

• Designed for vibration-prone industrial environments including rotating machinery systems

Standards & Compliance

• EMC immunity: EN 61000-6-2

• EMC emissions: EN 61000-6-4

• Electrical safety: EN 61010-1

• Hazardous area approvals:

• Class I, Division 2, Groups A–D, T4

• ATEX / IECEx Zone 2 (non-barrier configuration)

Typical Applications

• Compact turbine protection systems

• Skid-mounted compressors and rotating equipment

• OEM machinery with integrated monitoring requirements

• Small cabinet or space-constrained industrial installations

• Distributed condition monitoring systems requiring reduced footprint

FAQ

Q1: How does this mini rack differ from full-size 3500 racks?
It provides 7 module slots instead of 14, making it suitable for compact installations.

Q2: Can it support redundant power supplies?
Yes, within slot allocation limits, redundant power configurations are supported.

Q3: Is it compatible with all 3500 modules?
Yes, standard modules are supported as long as system slot capacity is not exceeded.

Specifications

• Brand: Bently Nevada

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
