Description
Product Overview
The Bently Nevada 3500/05-01-02-00-00-00 System Rack is a core component of the 3500 monitoring system. It integrates power supplies, monitor modules, and I/O components to ensure continuous machinery protection. Its modular design complies with API 670 standards, providing centralized power distribution and seamless communication between modules.
Technical Specifications
| Parameter |
Value |
| Model Number |
3500/05-01-02-00-00-00 |
| Module Type |
System Rack |
| Manufacturer |
Bently Nevada |
| Product Range |
3500 System |
| Condition |
Brand New |
| Dimensions |
48.2 × 27.4 × 26.6 cm |
| Weight |
5.95 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
TSI |
| Communication Service |
Ethernet Router |
| Status |
Active |
| Rack Options |
19-inch 14-slot, 12-inch 7-slot |
| Mounting Formats |
Panel, rack, bulkhead (not for mini-rack) |
| Slot Arrangement |
Left slots for power/interface, right for I/O |
| Compliance |
API 670 standards |
| Safety Features |
Supports intrinsic safety barriers, isolators |
Functional Description
The 3500/05-01-02-00-00-00 rack supports both full-size and mini-rack configurations, offering flexibility for diverse installations. Its standardized slot arrangement simplifies configuration, with power supplies and interface modules on the left and monitoring modules on the right. Optional components such as keyphasor modules and communication gateways expand system functionality.
Applications and Compatibility
The Bently Nevada 3500/05-01-02-00-00-00 System Rack suits hazardous area installations in power plants, compressor stations, and industrial facilities. Its robust design supports intrinsic safety barriers and galvanic isolators, ensuring reliable machinery protection. Compatibility with the broader 3500 series allows seamless integration and simplified maintenance.
Key Benefits
-
Compact 48.2x27.4x26.6cm dimensions fit diverse installation environments.
-
Heavy-duty 5.95kg build ensures durability and stability.
-
Multiple rack options provide flexibility for space-constrained setups.
-
Logical slot arrangement simplifies wiring and module integration.
-
Compliance with API 670 standards guarantees reliable machinery protection.
