Description
Overview
The Bently Nevada 330930‑060‑04‑05 extension cable is part of the 3300 NSv (Narrow Side‑View) Proximity Transducer System, engineered for machinery where limited mounting space or small shaft diameters prevent the use of standard 5 mm or 8 mm probes. This 6‑meter armored cable ensures stable, noise‑resistant signal transmission between NSv proximity probes and Proximitor sensors, supporting accurate vibration and position monitoring in demanding industrial environments.
Key Characteristics
-
6.0‑meter extension cable designed specifically for 3300 NSv systems
-
Stainless‑steel armored construction with FEP jacket for chemical and mechanical protection
-
Gold‑plated brass ClickLoc connectors for secure, vibration‑resistant mating
-
CableLoc retention system rated to 220 N pull strength
-
Suitable for compact machinery and small‑target applications
-
Backward‑compatible with earlier 3300 RAM probe systems
-
Supports radial vibration, axial position, and small‑target displacement measurements
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330930‑060‑04‑05 |
| Product Type |
3300 NSv Extension Cable |
| Cable Length |
6.0 m (19.7 ft) |
| Armor |
Stainless steel |
| Jacket Material |
FEP |
| Connector Type |
Gold‑plated ClickLoc |
| Cable Retention |
CableLoc, 220 N pull strength |
| System Compatibility |
3300 NSv Proximity Transducer System |
| Weight |
0.55 kg |
| Dimensions |
20.5 × 22.4 × 3.3 cm |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The 330930‑060‑04‑05 cable is engineered to maintain high‑quality signal transmission in installations requiring precise alignment between probe and Proximitor sensor. Its stainless‑steel armor and FEP jacket provide strong resistance to chemicals, abrasion, and mechanical stress, making it suitable for compressors, refrigeration systems, and process gas machinery.
The ClickLoc connector design ensures a secure, slip‑resistant connection that withstands vibration and thermal cycling. The CableLoc retention system reinforces the mechanical bond between the cable and probe assembly, supporting up to 220 N of pull force.
This cable is optimized for the 3300 NSv system, which is used when standard 5 mm or 8 mm probes cannot be installed due to space limitations or small shaft diameters. It is also compatible with earlier 3300 RAM probe systems, offering flexibility for system upgrades and mixed installations.
Application Scenarios
-
Centrifugal compressors
-
Refrigeration compressors
-
Process gas compressors
-
Machinery with limited mounting space
-
Small‑diameter shaft vibration monitoring
-
Chemical and high‑vibration industrial environments
FAQ
Q: Can this cable be used with standard 3300 XL 5 mm or 8 mm probes No. It is designed specifically for the 3300 NSv system, which uses different electrical characteristics.
Q: Is the cable suitable for corrosive or chemical environments Yes. The FEP jacket and stainless‑steel armor provide strong chemical resistance.
Q: Does this cable support older 3300 RAM probes Yes. It is backward‑compatible with earlier RAM probe and cable assemblies.
