Description
Overview
The Bently Nevada 330901-00-10-10-02-05 proximity probe is part of the 3300 NSv (Narrow Side‑View) series, engineered for precise vibration and shaft displacement measurement in compact or restricted‑access machinery. Designed for integration within the 3300 Proximity Transducer System, it provides stable, high‑resolution output suitable for continuous machinery protection.
Technical Specifications
| Parameter |
Specification |
| Model |
330901-00-10-10-02-05 |
| Probe Type |
3300 NSv Proximity Probe |
| Thread Size |
1/4‑28 UNF |
| Minimum Case Length |
1.0 inch |
| Cable Length |
1.0 m |
| Connector Type |
Miniature coaxial ClickLoc |
| Cable Type |
Standard NSv probe cable |
| System Compatibility |
3300 Proximity Transducer System |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
New |
| MOQ |
1 |
| Lead Time |
In stock |
| System |
TSI |
| Status |
Active |
Functional Characteristics
The 330901-00-10-10-02-05 probe is optimized for installations where space constraints limit the use of standard 8 mm probes. Its narrow‑profile design enables accurate displacement measurement in small housings, making it suitable for gearboxes, small pumps, and auxiliary rotating equipment.
The ClickLoc connector ensures secure engagement and maintains low‑noise signal transmission across the probe, extension cable, and Proximitor sensor. The 1/4‑28 UNF threaded body supports precise mechanical positioning, while the 1.0 m cable length provides flexibility for routing within compact machinery layouts.
Multiple global approvals allow deployment in hazardous or regulated industrial environments, supporting long‑term reliability and consistent measurement performance.
Application Scenarios
This NSv probe is commonly used in:
-
Small-frame motors and pumps
-
Gearboxes with limited mounting space
-
Auxiliary rotating equipment
-
Machinery requiring narrow‑profile displacement sensing
-
API 670–aligned monitoring systems
FAQ
Q: How does the NSv probe differ from standard 8 mm probes? A: NSv probes are designed for installations with limited radial clearance, offering the same measurement accuracy in a smaller mechanical footprint.
Q: Is this probe compatible with standard 3300 XL extension cables? A: No. NSv probes require NSv‑specific extension cables and Proximitor sensors for correct calibration.
Q: Can this model be used in hazardous areas? A: Yes. It carries multiple international approvals suitable for classified industrial environments.
