Overview
The 330709-000-030-10-02-00 Bently Nevada probe is part of the 3300 XL 11 mm Proximity Transducer System, designed for extended-range vibration and displacement monitoring. Its larger 11 mm tip provides a wider linear range compared to standard 8 mm probes, making it ideal for applications requiring precise non-contact measurements in fluid film bearing machines.
Technical Specifications
| Parameter |
Value |
|
Model Number
|
330709-000-030-10-02-00 |
|
Product Type
|
3300 XL 11 mm Proximity Probe
|
| Manufacturer |
Bently Nevada
|
| Condition |
Brand New
|
|
System Compatibility
|
3300 XL Proximitor Sensor + Extension Cable
|
|
Thread Size
|
M16 × 1.5
|
|
Minimum Case Length
|
30 mm
|
|
Cable Length
|
1.0 m (3.3 ft)
|
|
Output Sensitivity
|
3.94 V/mm
|
| Connector |
Miniature coaxial ClickLoc
|
| Weight |
0.06 kg
|
| Dimensions |
1.8 × 1.6 × 123 cm
|
| Certifications |
CSA, ATEX, IECEx
|
|
HS Code
|
8537101190 |
| Origin |
USA |
| MOQ |
1 |
| Availability |
In Stock
|
Functional Highlights
-
Extended linear range due to 11 mm probe tip.
-
Suitable for axial position, ramp differential expansion, and rod position monitoring.
-
Effective in tachometer, zero-speed, and Keyphasor phase reference applications.
-
Designed to replace legacy 7200-series 11 mm and 14 mm transducer systems.
-
Requires full system upgrade with compatible 3300 XL 11 mm components for retrofit installations.
Application Scenarios
-
Steam turbine expansion monitoring.
-
Reciprocating compressor rod position measurement.
-
Axial shaft position monitoring in large rotating machinery.
-
Tachometer and phase reference signal generation.
FAQ
Q: How does this probe differ from the 8 mm series? A: The 330709-000-030-10-02-00 offers a larger tip size and extended linear range, making it suitable for applications requiring higher displacement measurement accuracy.
Q: Can it replace older 7200-series probes? A: Yes, but all system components must be upgraded to 3300 XL 11 mm parts for compatibility.
Q: Is it certified for hazardous environments? A: Yes, it carries CSA, ATEX, and IECEx approvals for safe use in explosive atmospheres.
