Description
Overview
The Bently Nevada 330130‑40‑00‑00 is a standard extension cable designed for use within the 3300 XL Proximity Transducer System. It provides stable, low‑noise signal transmission between 3300 XL proximity probes and their associated Proximitor sensors, ensuring accurate vibration and displacement measurements in industrial machinery.
Design and Construction
This extension cable features a 4.0‑meter (13.1 ft) length, offering installation flexibility while maintaining signal integrity over extended distances. The cable includes a connector protector to safeguard the connection interface in harsh operating environments.
The 330130‑40‑00‑00 is fully interchangeable with non‑XL 3300‑series 5 mm and 8 mm components. Although the packaging differs from earlier models, it maintains the same 4‑hole mounting pattern and fits existing mounting footprints, simplifying system upgrades and replacements.
When paired with 8 mm probes, the cable supports enhanced mechanical robustness due to the thicker PPS‑molded probe tip and larger probe body diameter. This combination improves durability in applications involving high vibration, oil contamination, or mechanical stress.
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330130‑40‑00‑00 |
| Product Type |
3300 XL Standard Extension Cable |
| Cable Length |
4.0 m (13.1 ft) |
| Connector Type |
Standard with connector protector |
| System Compatibility |
3300 XL Proximity Transducer System |
| Backward Compatibility |
Non‑XL 3300 5 mm & 8 mm components |
| Mounting Pattern |
Standard 4‑hole configuration |
| Measurement Support |
Vibration, position, Keyphasor applications |
| Weight |
0.08 kg |
| Dimensions |
112 × 1.5 × 1.2 cm |
| Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| HS Code |
8537101190 |
| System |
TSI compatible |
Functional Description
The 330130‑40‑00‑00 extension cable ensures reliable transmission of the probe’s displacement signal to the Proximitor sensor. Its design minimizes electrical noise and maintains the accuracy of both static and dynamic measurements. The cable’s rugged construction and protective connector design make it suitable for fluid‑film bearing machines, speed measurement points, and compressor monitoring systems.
Multiple agency approvals and full interchangeability with XL and non‑XL components allow the cable to be used across a wide range of industrial environments without requiring system recalibration.
Application Areas
-
Steam and gas turbines
-
Compressors and expanders
-
Gearboxes and industrial motors
-
Fluid‑film bearing machines
-
Keyphasor and speed reference systems
-
Machinery requiring extended cable routing
FAQ
Q: Is this cable compatible with older 3300‑series components Yes. It is fully interchangeable with non‑XL 3300 5 mm and 8 mm systems.
Q: What is the length of this extension cable It includes a 4.0‑meter (13.1 ft) standard cable.
Q: Does the cable include protective hardware Yes. It comes with a connector protector for added durability.
Q: Can this cable be used in high‑vibration environments Yes. When paired with 8 mm probes, the system offers enhanced mechanical robustness.
