Bently Nevada 330130-080-12-05 3300 XL Standard Extension Cable

The Bently Nevada 330130-080-12-05, also cataloged as the 330130 3300 XL Standard Extension Cable, provides electrical signal extension between proximity probes and monitor systems within the 3300 XL Proximity Transducer System.

Hardware Specifications

Parameter	Specification
Model	330130-080-12-05
Brand	Bently Nevada
Product Type	3300 XL Standard Extension Cable
Origin	USA
Weight	0.98 kg
Dimensions	30.5 x 31.5 x 5 cm estimated shipping size
Operating Temp	Not specified
Power Consumption	Passive cable component, no external power consumption
Cable Length	8.0 meters (26.2 feet)
Cable Construction	FluidLoc cable with connector protector
Connector Protection	Connector protector installed
Agency Approvals	CSA, ATEX, IECEx
Cable Application	Signal transmission between proximity probe and monitoring electronics
Tariff Code	8537101190

Eddy-Current Signal Extension and Rotor Dynamics Interface

The 3300 XL Standard Extension Cable maintains the electrical connection path required for eddy-current proximity measurement circuits. Therefore, it supports accurate transmission of vibration, shaft position, and gap measurement signals between the probe and the associated proximity sensor interface.

The cable design supports Bently Nevada TSI applications where probe scaling, gap voltage validation, and rotor dynamics monitoring require consistent signal characteristics. Moreover, the FluidLoc cable construction reduces the risk of fluid migration through the cable structure during field operation.

The connector protector provides additional mechanical protection at the connection point. In addition, the cable configuration supports CSA, ATEX, and IECEx approved installation environments when used with compatible system components.

Frequently Asked Questions

Q: What is the function of the Bently Nevada 330130-080-12-05 cable?
A: The cable extends the electrical connection between a 3300 XL proximity probe and the monitoring system input interface while maintaining eddy-current measurement signal transmission.

Q: Does the 330130-080-12-05 cable require external power?
A: No. The extension cable is a passive component and does not consume external electrical power.

Q: What cable protection features are included in this model?
A: This model includes FluidLoc cable construction and a connector protector to improve protection against fluid migration and mechanical stress.

Field Installation Guidelines

Install the 330130-080-12-05 extension cable according to the approved Bently Nevada proximity transducer system wiring requirements.

• Route the cable away from high-current power cables and strong electromagnetic interference sources.
• Maintain proper separation between signal wiring and motor or drive power conductors.
• Verify connector engagement before system commissioning.
• Avoid sharp bends, excessive pulling force, and mechanical damage to the cable jacket.
• Connect cable shielding according to the monitoring system grounding specification.
• Confirm probe, extension cable, and proximity monitor compatibility before operation.
• Check gap voltage values during commissioning to verify correct eddy-current probe operation.
