Description
Overview
The 330104-02-09-05-01-00 Proximity Probe from Bently Nevada is part of the 3300 XL series, engineered for precise vibration and shaft position monitoring in fluid-film bearing machines and other critical rotating equipment. Its armored construction and compact design make it suitable for installations requiring mechanical protection and reliable performance under demanding industrial conditions.
Technical Specifications
-
Model Number: 330104-02-09-05-01-00
-
Product Type: 8 mm Proximity Probe
-
Manufacturer: Bently Nevada
-
Condition: Brand New
-
Compatible System: 3300 XL Proximity Transducer System
-
Thread Size: M10 × 1
-
Minimum Unthreaded Length: 20 mm
-
Minimum Case Length: 90 mm
-
Cable Length: 0.5 m (1.6 ft) integral cable
-
Connector Type: Miniature coaxial ClickLoc™ connector with protective cover
-
Construction: Armored probe for enhanced durability
-
Output: Voltage proportional to distance (supports static and dynamic measurements)
-
Applications Supported: Radial vibration, axial position, Keyphasor reference, tachometer, and speed measurements
-
Dimensions: 1.8 × 1.6 × 123 cm
-
Weight: 0.06 kg
-
HS Code: 8537101190
-
Origin: USA
-
MOQ: 1
-
Compliance: API 670 standard
-
Certifications: CSA, ATEX, IECEx approvals
Functional Description
The 330104-02-09-05-01-00 probe is designed for accurate measurement of both static shaft position and dynamic vibration. Its armored housing provides mechanical protection, ensuring reliable operation in harsh environments. The ClickLoc™ connector simplifies installation by providing secure, tool-free connections with added protection against loosening.
This probe integrates seamlessly with other 3300 XL components, including extension cables and Proximitor sensors, ensuring full interchangeability and simplified system upgrades. Its compact dimensions and rugged design make it particularly valuable for monitoring fluid-film bearing machines and high-speed rotating equipment.
Application Scenarios
-
Radial vibration monitoring in turbines and compressors
-
Axial thrust position measurement in generators and reciprocating machinery
-
Keyphasor reference and tachometer applications in rotating equipment
-
Hazardous area installations requiring CSA, ATEX, and IECEx compliance
-
Predictive maintenance programs across oil & gas, power generation, and manufacturing sectors
FAQ
Q: What is the cable length of this probe? A: The probe includes a 0.5 m (1.6 ft) integral cable.
Q: Is this probe armored? A: Yes, it features armored construction for enhanced durability in harsh environments.
Q: What measurements does this probe support? A: It supports vibration, shaft position, Keyphasor reference, tachometer, and speed measurements.
Q: Is it interchangeable with other 3300 XL components? A: Yes, it is fully compatible with extension cables and Proximitor sensors in the 3300 XL series.
