Description
Overview
The Bently Nevada 330104‑00‑20‑10‑01‑05 proximity probe is part of the 3300 XL 8 mm transducer family, engineered for accurate displacement and vibration measurement in fluid‑film bearing machinery. Its armored construction and reinforced PPS sensing tip provide enhanced durability for installations exposed to mechanical stress, contamination, or elevated temperatures.
Key Characteristics
-
8 mm probe tip with molded PPS encapsulation for improved coil protection
-
M10 × 1 threaded stainless‑steel housing with armor
-
1.5‑meter integrated coaxial cable with ClickLoc miniature connector
-
Designed for static position, dynamic vibration, and Keyphasor reference measurements
-
Fully interchangeable with 3300 XL and legacy 3300 5 mm / 8 mm components
-
Suitable for hazardous environments with CSA, ATEX, and IECEx approvals
-
Optimized for long‑term reliability in demanding industrial applications
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330104‑00‑20‑10‑01‑05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
M10 × 1 |
| Housing |
Stainless steel with armor |
| Tip Material |
PPS molded plastic |
| Cable Length |
1.5 m (4.9 ft) |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Principle |
Eddy‑current displacement |
| Output |
Voltage proportional to probe‑target gap |
| Interchangeability |
XL and non‑XL 3300 5 mm / 8 mm systems |
| Certifications |
CSA, ATEX, IECEx |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| System Compatibility |
3300 XL Proximity Transducer System |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The 330104‑00‑20‑10‑01‑05 probe is engineered for high‑accuracy eddy‑current displacement measurement. Its armored cable and reinforced PPS tip provide mechanical protection in harsh environments, while the M10 × 1 threaded body supports secure installation in confined or high‑vibration locations.
The probe forms part of a three‑component transducer system—probe, extension cable, and Proximitor sensor. When installed as a matched set, it delivers precise monitoring of:
The probe’s electrical and physical interchangeability with legacy 3300 components simplifies system upgrades and maintenance. Its hazardous‑area certifications support deployment in oil & gas, power generation, and process industries.
Application Scenarios
FAQ
Q: Can this probe replace older 3300 5 mm or 8 mm probes? A: Yes. It is electrically and mechanically compatible when installed with matched cable lengths.
Q: What advantage does the armored version provide? A: Armor protects the cable from abrasion, mechanical impact, and routing stress.
Q: Is this probe suitable for hazardous locations? A: Yes. It carries CSA, ATEX, and IECEx approvals.
