Description
Overview
The Bently Nevada 330104‑00‑18‑10‑02‑CN proximity probe is an 8 mm eddy‑current sensor designed for precise non‑contact measurement of shaft vibration and displacement in rotating machinery. As part of the 3300 XL Proximity Transducer System, it delivers stable linearity, long‑term durability, and reliable performance in demanding industrial environments.
Design and Construction
This configuration features an armored M10 × 1 threaded probe, engineered for installations requiring enhanced mechanical protection. The probe includes a minimum case length of 180 mm, providing extended reach for deeper mounting sleeves or housings. A 1.0 m integral cable terminated with a miniature ClickLoc coaxial connector ensures secure, repeatable electrical connections.
The 330104‑00‑18‑10‑02‑CN complies with API 670 requirements for machinery protection systems, covering linear range, accuracy, mechanical configuration, and temperature stability. Its rugged construction and armored design make it suitable for harsh operating conditions, including oil and gas, petrochemical, and power generation environments.
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330104‑00‑18‑10‑02‑CN |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
M10 × 1 |
| Case Length |
180 mm minimum |
| Cable Length |
1.0 m |
| Cable Type |
Armored |
| Connector |
Miniature coaxial ClickLoc |
| System Compatibility |
3300 XL Proximity Transducer System |
| Backward Compatibility |
Non‑XL 3300 5 mm & 8 mm components |
| Certifications |
API 670 compliant |
| Measurement Capability |
Static position + dynamic vibration |
| Operating Temperature |
–35 °C to +120 °C (typical probe rating) |
| Storage Temperature |
–51 °C to +177 °C |
| Weight |
0.55 kg |
| Dimensions |
20.5 × 22.4 × 3.3 cm |
| Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| HS Code |
8537101190 |
| System |
TSI compatible |
Functional Description
The 330104‑00‑18‑10‑02‑CN probe provides a voltage output proportional to the distance between the probe tip and a conductive target surface. When paired with a 3300 XL Proximitor Sensor and extension cable, it delivers high‑resolution vibration and displacement measurements essential for machinery protection.
The probe’s armored construction enhances durability, while full electrical and physical interchangeability with non‑XL 3300‑series components simplifies system upgrades and maintenance. Its compliance with API 670 ensures consistent performance across a wide range of industrial applications.
Application Areas
-
Steam and gas turbines
-
Centrifugal and reciprocating compressors
-
Petrochemical and refinery equipment
-
Power generation machinery
-
Industrial rotating equipment requiring extended probe reach
FAQ
Q: Does this model include hazardous‑area approvals The “CN” suffix indicates a China‑specific configuration; hazardous‑area approvals depend on system requirements and may vary.
Q: Is the probe compatible with non‑XL components Yes. It is backward compatible with 3300 5 mm and 8 mm systems.
Q: What cable length is included This configuration includes a 1.0 m armored cable.
Q: Does the probe meet API 670 requirements Yes. It complies with API 670 standards for machinery protection.
