Description
Overview
The Bently Nevada 330104‑00‑08‑10‑01‑00 proximity probe is part of the 3300 XL 8 mm transducer family, designed for precise non‑contact measurement of shaft vibration and displacement. Its rugged construction and stable electrical characteristics make it suitable for continuous monitoring of rotating equipment in demanding industrial environments.
Design and Construction
This probe uses an M10×1 threaded body and includes an armored 1.0‑meter cable for enhanced protection in high‑vibration or mechanically exposed installations. The miniature coaxial ClickLoc connector ensures a secure, vibration‑resistant connection that maintains shielding integrity throughout the system.
The 330104‑00‑08‑10‑01‑00 is engineered to deliver consistent linearity and measurement accuracy when paired with compatible 3300 XL Proximitor sensors. Its compact dimensions support installation in tight spaces while maintaining full system compatibility.
Technical Specifications
| Parameter |
Specification |
| Model |
330104‑00‑08‑10‑01‑00 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Type |
M10×1 |
| Cable Length |
1.0 m (armored) |
| Connector |
Miniature coaxial ClickLoc with protector |
| Measurement Type |
Static position and dynamic vibration |
| System Compatibility |
3300 Proximity Transducer System |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Minimum Order |
1 unit |
| Product Status |
Active |
| System |
TSI |
Performance Characteristics
The probe generates a voltage output proportional to the distance between the probe tip and the target surface, enabling accurate displacement and vibration measurements. It is suitable for fluid‑film bearing machines and supports Keyphasor reference and speed measurement applications.
The armored cable construction provides additional protection against mechanical damage, making the probe suitable for installations with elevated vibration levels or where cable routing is exposed to potential impact.
Application Scenarios
-
Radial vibration and shaft displacement monitoring
-
Axial position measurement on turbines and compressors
-
Keyphasor reference signal acquisition
-
Speed measurement on rotating machinery
-
High‑vibration industrial environments requiring armored cabling
FAQ
Q: Can this probe be used with older 3300 series components? A: It is designed for the 3300 XL system; compatibility with non‑XL components may be limited.
Q: What type of machines typically use this probe? A: Turbines, compressors, pumps, and other rotating equipment with fluid‑film bearings.
Q: Does the armored cable affect measurement accuracy? A: No. The armored design protects the cable without altering electrical performance.
