Description
Overview
The 330103-00-22-10-12-05 Proximity Probe from Bently Nevada is a high-performance 8 mm sensor designed for non-contact vibration and displacement monitoring in critical rotating machinery. Built with advanced mechanical reinforcement and fluid-resistant cabling, it ensures reliable operation in hazardous and high-vibration environments.
Technical Specifications
-
Model Number: 330103-00-22-10-12-05
-
Product Type: 8 mm Proximity Probe
-
Manufacturer: Bently Nevada
-
Condition: Brand New
-
Compatible System: 3300 XL Proximity Transducer System
-
Armored Case Length: 220 mm
-
Cable Length: 1.0 m FluidLoc™ cable
-
Connector Type: Gold-plated ClickLoc™ connector (finger-tight, audible lock)
-
Cable Retention Strength: 330 N (75 lbf) via CableLoc™ design
-
Protective Technology: FluidLoc™ prevents oil migration through cable interior
-
Certifications: CSA, ATEX, IECEx approvals for hazardous environments
-
Dimensions: 28 × 26 × 6 cm
-
Weight: 1.48 kg
-
HS Code: 8537101190
-
Origin: USA
-
MOQ: 1
-
Compliance: API 670 standard
-
Compatibility: Works with both standard and Extended Temperature Range (ETR) systems
Functional Description
The 330103-00-22-10-12-05 probe incorporates Bently Nevada’s TipLoc™ molding process, which creates a strong mechanical bond between the probe tip and body, enhancing durability under mechanical stress. The CableLoc™ system provides superior cable retention strength, preventing accidental disconnection in high-vibration environments.
FluidLoc™ technology prevents oil contamination inside the cable, protecting sensitive monitoring systems. The probe connects directly to 3300 XL Proximitor Sensors, which feature electrical isolation and flexible mounting options. Its design reduces installation time while ensuring long-term measurement reliability.
Application Scenarios
-
Steam turbine vibration monitoring
-
Compressor shaft displacement measurement
-
Generator condition monitoring in hazardous environments
-
Predictive maintenance programs requiring high-reliability sensors
FAQ
Q: What makes this probe suitable for hazardous environments? A: It carries CSA, ATEX, and IECEx certifications and features armored construction with fluid-resistant cabling.
Q: Is this probe compatible with Extended Temperature Range (ETR) systems? A: Yes, it is compatible, but accuracy will be limited to ETR specifications.
Q: How secure is the cable connection? A: The CableLoc™ system provides 330 N (75 lbf) pull strength, ensuring secure connections in high-vibration conditions.
