Description
Overview
The Bently Nevada 330103‑00‑15‑10‑02‑CN proximity probe is part of the 3300 XL 8 mm eddy‑current transducer system, engineered for precise shaft vibration and position measurement in fluid‑film bearing machinery. This model is designed to meet regional installation requirements while maintaining full compatibility with the global 3300 XL platform. Its stable electrical characteristics and rugged mechanical design ensure long‑term reliability in demanding industrial environments.
Key Characteristics
-
8 mm eddy‑current probe for displacement and vibration monitoring
-
M10 × 1 threaded stainless‑steel housing
-
Minimum unthreaded length: 0 mm
-
Case length: 140 mm
-
1.0‑meter integrated coaxial cable with ClickLoc miniature connector
-
Fully compliant with API 670 mechanical and performance requirements
-
Interchangeable with all 3300 XL and legacy 3300 5 mm / 8 mm components
-
Designed for regional (CN) specifications while maintaining global performance standards
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330103‑00‑15‑10‑02‑CN |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
M10 × 1 |
| Minimum Unthreaded Length |
0 mm |
| Case Length |
140 mm |
| Cable Length |
1.0 m |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Principle |
Eddy‑current displacement |
| Calibration |
Factory‑set for AISI 4140 steel (other materials optional) |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| System Compatibility |
3300 XL Proximity Transducer System |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The 330103‑00‑15‑10‑02‑CN probe is engineered to deliver accurate displacement and vibration measurements across a wide operating range. As part of the 3300 XL system, it forms a matched transducer assembly with an extension cable and Proximitor sensor, ensuring stable performance without requiring component matching or bench calibration.
The probe complies with API 670 requirements for:
-
Mechanical configuration
-
Linear range
-
Sensitivity
-
Temperature stability
Its 1.0‑meter cable and compact mechanical dimensions support installation in confined or high‑density machinery layouts. The ClickLoc connector ensures secure electrical contact and reduces the risk of accidental disconnection.
This model is suitable for both standard vibration monitoring and overspeed protection applications when paired with the appropriate Proximitor sensor.
Application Scenarios
FAQ
Q: What does the “CN” suffix indicate? A: It denotes a configuration tailored for regional installation requirements while maintaining full 3300 XL performance.
Q: Is this probe compatible with older 3300 systems? A: Yes. It is fully interchangeable with both XL and non‑XL 3300 5 mm and 8 mm components.
Q: Can the probe be calibrated for different shaft materials? A: Yes. Custom calibration is available upon request.
