Description
Overview
The Bently Nevada 330103‑00‑05‑10‑02‑CN proximity probe is part of the 3300 XL 8 mm transducer family and is engineered for precise non‑contact measurement of shaft vibration and displacement. This model features a short 0.5‑meter cable configuration and is tailored for installations requiring compact probe assemblies, particularly in applications with limited mounting space.
Design and Construction
This probe uses an M10×1 threaded body and incorporates a 50 mm case length, making it suitable for confined installation areas. The cable is factory‑molded and terminated with a gold‑plated ClickLoc miniature coaxial connector, providing a secure, vibration‑resistant connection and maintaining shielding integrity.
The 330103‑00‑05‑10‑02‑CN is designed to operate as part of the complete 3300 XL transducer system, working with compatible extension cables and Proximitor sensors to deliver accurate static and dynamic measurements.
Technical Specifications
| Parameter |
Specification |
| Model |
330103‑00‑05‑10‑02‑CN |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Type |
M10×1 |
| Case Length |
50 mm |
| Cable Length |
0.5 m |
| Connector |
Gold‑plated miniature coaxial ClickLoc |
| Measurement Type |
Static position and dynamic vibration |
| Certifications |
CSA, ATEX, IECEx |
| Compliance |
API 670 |
| System Compatibility |
3300 XL Proximity Transducer System |
| Weight |
0.14 kg |
| Dimensions |
20.5 × 22.5 × 3.5 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Minimum Order |
1 unit |
| Product Status |
Active |
| System |
TSI |
Performance Characteristics
The probe generates a voltage output proportional to the distance between the probe tip and the target surface, enabling accurate gap and vibration measurements. Its compact design supports installations in restricted spaces while maintaining the durability and performance expected from the 3300 XL series.
The 330103‑00‑05‑10‑02‑CN meets API 670 requirements and is certified for hazardous‑area use, making it suitable for critical applications in power generation, petrochemical processing, and heavy industrial environments.
Application Scenarios
-
Turbine and compressor vibration monitoring
-
Shaft displacement and axial position measurement
-
Keyphasor reference signal acquisition
-
Speed measurement on rotating machinery
-
Installations requiring short‑cable probe configurations
FAQ
Q: What makes this model suitable for compact installations Its 50 mm case length and 0.5 m cable allow mounting in tight spaces without compromising measurement accuracy.
Q: Is this probe compatible with standard 3300 XL extension cables Yes. It is designed to operate with the full 3300 XL transducer system.
Q: Does this model meet hazardous‑area requirements It carries CSA, ATEX, and IECEx approvals for use in classified environments.
