Description
Overview
The Bently Nevada 330103‑00‑05‑10‑02‑05 proximity probe is part of the 3300 XL 8 mm transducer system, engineered for precise shaft vibration and position measurement in fluid‑film bearing machinery. Its durable mechanical construction, stable electrical characteristics, and compatibility with global 3300 XL components make it a reliable choice for continuous machinery protection applications.
Key Characteristics
-
8 mm eddy‑current probe for displacement and vibration monitoring
-
M10 × 1 threaded stainless‑steel housing
-
1.0‑meter integrated coaxial cable
-
Miniature ClickLoc connector for secure, vibration‑resistant connections
-
Gold‑plated connector contacts for corrosion resistance
-
Fully compatible with 3300 XL extension cables and Proximitor sensors
-
Meets CSA, ATEX, and IECEx hazardous‑area certifications
-
Suitable for high‑temperature, high‑vibration industrial environments
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330103‑00‑05‑10‑02‑05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
M10 × 1 |
| Cable Length |
1.0 m (3.3 ft) |
| Cable Type |
Unarmored coaxial cable |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Principle |
Eddy‑current displacement |
| Output |
Voltage proportional to probe‑target gap |
| Certifications |
CSA, ATEX, IECEx |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| System Compatibility |
3300 XL Proximity Transducer System |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The 330103‑00‑05‑10‑02‑05 probe is designed to deliver accurate displacement and vibration measurements for rotating machinery. Its M10 × 1 threaded housing supports secure installation, while the ClickLoc connector ensures a reliable electrical interface that resists loosening under vibration.
The probe’s sensing element produces a voltage proportional to the distance between the probe tip and the conductive target surface, enabling precise monitoring of:
Gold‑plated connector contacts enhance corrosion resistance, ensuring long‑term signal integrity. The probe is lightweight and easy to install, making it suitable for both new installations and system upgrades.
Application Scenarios
FAQ
Q: Does this probe require a specific Proximitor sensor? Yes. It is designed for use with 3300 XL Proximitor sensors for optimal performance.
Q: Can this probe be used in hazardous environments? Yes. It meets CSA, ATEX, and IECEx certifications.
Q: Is the connector resistant to vibration? The ClickLoc connector includes a locking mechanism that prevents loosening during operation.
