Description
Overview
The Bently Nevada 330102‑00‑60‑05‑02‑05 proximity probe is part of the 3300 XL 8 mm transducer family, designed for precise shaft vibration and displacement measurement in rotating machinery. Its mechanical robustness, stable linearity, and compatibility with the 3300 XL Proximity Transducer System make it a dependable choice for long‑term condition monitoring.
Key Characteristics
-
8 mm eddy‑current probe optimized for both static and dynamic measurements
-
3/8‑24 UNF threaded body with armored cable protection
-
0.5 m (1.6 ft) integral cable with ClickLoc miniature coaxial connector
-
Enhanced PPS‑encapsulated coil for improved mechanical durability
-
Fully compatible with 3300 XL extension cables and Proximitor sensors
-
Certified for global hazardous‑area standards (CSA, ATEX, IECEx)
-
Suitable for TSI (Turbine Supervisory Instrumentation) systems
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330102‑00‑60‑05‑02‑05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
3/8‑24 UNF |
| Cable Length |
0.5 m (1.6 ft) |
| Connector |
Miniature coaxial ClickLoc |
| Case Length |
6.0 in minimum |
| System Compatibility |
3300 XL Proximity Transducer System |
| Certifications |
CSA, ATEX, IECEx |
| Operating Temperature |
–35 °C to +120 °C (typical probe rating) |
| Storage Temperature |
–51 °C to +177 °C |
| Weight |
0.08 kg |
| Dimensions |
112 × 1.5 × 1.2 cm |
| Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| HS Code |
8537101190 |
Functional Description
The 330102‑00‑60‑05‑02‑05 probe uses an eddy‑current sensing principle to measure shaft displacement and vibration with high repeatability. Its 8 mm tip design provides a balanced combination of linear range and installation flexibility, making it suitable for medium‑clearance machinery.
The molded PPS tip encapsulates the probe coil, offering improved resistance to impact, thermal cycling, and chemical exposure. The armored cable option further enhances survivability in high‑temperature or mechanically exposed installations.
The probe integrates seamlessly with the 3300 XL system and maintains full interchangeability with other XL‑series components, eliminating the need for individual calibration. Its compliance with major hazardous‑area certifications supports deployment in refineries, power plants, and other safety‑critical environments.
Applications
-
Steam and gas turbines
-
Compressors and expanders
-
Industrial pumps and motors
-
Gearboxes and generators
-
TSI monitoring systems
-
Machinery operating in hazardous or high‑temperature zones
FAQ
Q: Is the probe interchangeable with other 3300 XL components? Yes. All 3300 XL probes, extension cables, and Proximitor sensors are designed for full interchangeability.
Q: What advantages does the 8 mm probe offer? It provides a wider linear range than 5 mm probes while maintaining compact installation requirements.
Q: Does the probe support hazardous‑area installation? Yes. It carries CSA, ATEX, and IECEx approvals.
