Description
Overview
The Bently Nevada 330102‑00‑20‑10‑02‑00 proximity probe is part of the 3300 XL NSv (Narrow Side‑view) transducer family, engineered specifically for machinery where installation space is extremely limited. This configuration provides accurate non‑contact shaft vibration and position measurements in compact compressor housings, counter‑bored installations, and other restricted mounting locations.
Functional Characteristics
This NSv configuration includes a miniature 8 mm probe, matching NSv extension cable, and an XL NSv Proximitor Sensor. Together, they deliver precise displacement and vibration measurements while maintaining the same electrical performance expected from the 3300 XL series.
The 330102‑00‑20‑10‑02‑00 probe is optimized for small‑target applications, such as radial vibration on shafts under 51 mm (2 in) diameter or axial position measurements on flat targets smaller than 15 mm (0.6 in). Its compact form factor allows installation in locations where standard 5 mm or 8 mm probes cannot be used due to side‑view or rear‑view obstructions.
A miniature ClickLoc coaxial connector ensures secure, repeatable connections while maintaining a low‑profile geometry suitable for tight spaces.
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330102‑00‑20‑10‑02‑00 |
| Probe Type |
3300 XL NSv 8 mm Proximity Probe |
| System Compatibility |
3300 XL NSv Proximity Transducer System |
| Target Size Suitability |
Shafts < 51 mm; flat targets < 15 mm |
| Cable Type |
NSv extension cable (included in system) |
| Connector |
Miniature coaxial ClickLoc |
| Measurement Capability |
Static position + dynamic vibration |
| Typical Applications |
Compressors, small shafts, restricted mounting areas |
| Operating Temperature |
–35 °C to +120 °C (typical probe rating) |
| Storage Temperature |
–51 °C to +177 °C |
| Weight |
0.12 kg |
| Dimensions |
20.5 × 22.2 × 3.7 cm |
| Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| HS Code |
8537101190 |
| System |
TSI compatible |
Application Areas
-
Centrifugal air compressors
-
Refrigeration compressors
-
Process gas compressors
-
Small‑shaft machinery
-
Installations with counter‑bore, side‑view, or rear‑view restrictions
-
Compact housings requiring narrow‑profile probes
FAQ
Q: What makes the NSv probe different from standard 8 mm probes It is designed for restricted spaces where standard probes cannot be installed due to geometric limitations.
Q: Can this probe measure both vibration and position Yes. It provides both static displacement and dynamic vibration signals.
Q: What types of machines typically use NSv probes Small compressors, compact housings, and machinery with limited probe access.
Q: Is the connector compatible with standard XL components Yes. The ClickLoc connector ensures secure integration with NSv extension cables and Proximitor sensors.
